Cisco 10GBASE-LR S-Class SFP Module for 10-Gigabit Ethernet Deployments, Hot Swappable, 5-Year Standard Warranty (SFP-10G-LR-S=)

10GBASE-LR S-Class SFP Module for 10-Gigabit Ethernet Deployments, Hot Swappable, 5-Year Standard Warranty (SFP-10G-LR-S=)

---

The Cisco 10GBASE-LR-S SFP Module delivers a wide variety of 10-Gigabit Ethernet connectivity options for data centre, enterprise and service provider applications over single-mode fibre. This hot-swappable input/output transceiver plugs into an Ethernet SFP+ port of a Cisco switch and offers optical interoperability with 10GBASE XENPAK, 10GBASE X2 and 10GBASE XFP interfaces on the same link.

---

Performance
Auto MDI/MDI-X	Yes
Duplex system	Full
Cabling technology	10GBASE-LR
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u
Wavelength	1310 nm
Maximum transfer distance	10000 m
SFP transceiver standard	LR
Fiber cable diameters supported (core/cladding)	9/125 µm
Fiber optic connector	LC, PC
Single-mode fiber (SMF) supported	Yes
Interface type	SFP+
Maximum data transfer rate	10000 Mbit/s
SFP transceiver type	Fiber optic

Features
Certification	MSA
Country of origin	China
Hot-Plug support	Yes

Operational conditions
Storage relative humidity (H-H)	0 - 95%
Operating relative humidity (H-H)	0 - 95%
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 85 °C

Weight & dimensions
Height	8.5 mm
Depth	56.5 mm
Width	13.4 mm

Packaging data
Package weight	90.7 g
Package height	44.5 mm
Package depth	158.8 mm
Package width	143 mm
Number of products included	1 pc(s)

Logistics data
Harmonized System (HS) code	85369010
Quantity per pack	1 pc(s)
