Yealink

Yealink - MCore4-MS

Yealink - MCore4-MS

£1,589.39 GBP
£1,589.39 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

1306064

Low stock: 2 left

  • Intel® Core Ultra 5, Built-in NPU 34Tops Computing Power
  • Enterprise-level Security
  • IP connection with Touch console
  • Built-in EDID module, CEC support
MCore4-MS -Video Conferencing AI PC

The MCore Kit serves as the core component of Yealink’s 4th-gen MVC system, featuring a high-performance AI PC MCore 4 and a touch panel MTouch Plus. Designed specifically for video conference rooms, it offers a flexible and reliable deployment solution. Additionally, MCore 4 supports Windows Autopilot, enabling IT administrators to automatically configure new devices for seamless integration into the existing IT ecosystem.

Processor
Processor manufacturer Intel
Processor family Intel Core Ultra 5
Processor generation Intel® Core™ Ultra (Series 1)
Processor model 125H
Processor cores 14
Processor threads 18
Processor boost frequency 4.5 GHz
Performance cores 4
Efficient cores 8
Low Power Efficient-cores 2
Performance-core Max Turbo Frequency 4.5 GHz
Efficient-core Max Turbo Frequency 3.6 GHz
Low Power Efficient-core Max Turbo Frequency 2.5 GHz
Performance-core base frequency 1.2 GHz
Efficient-core base frequency 0.7 GHz
Low Power Efficient-core Base Frequency 700 MHz
Processor cache 18 MB
Processor cache type Smart Cache
Number of processors installed 1
Maximum turbo power 115 W
Processor base power 28 W
Neural processor unit (NPU)
Neural processor unit (NPU) Intel AI Boost
Sparsity support Yes
Windows Studio effects support Yes
AI software frameworks supported by NPU DirectML, ONNX RT, OpenVINO, Windows ML
Memory
Internal memory 16 GB
Internal memory type DDR5-SDRAM
Storage
Total storage capacity 256 GB
Optical drive type No
Storage media SSD
Total SSDs capacity 256 GB
Graphics
Discrete graphics card No
On-board graphics card Yes
Discrete graphics card model Not available
On-board GPU manufacturer Intel
On-board graphics card family Intel Arc Graphics
On-board graphics card model Intel Arc Graphics
Network
Ethernet LAN Yes
Ethernet LAN data rates 10,100,1000 Mbit/s
Wi-Fi Yes
Top Wi-Fi standard Wi-Fi 6 (802.11ax)
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth Yes
Bluetooth version 5.2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
HDMI ports quantity 4
HDMI version 2.0/2.1
Ethernet LAN (RJ-45) ports 1
Headphone outputs 1
Design
Chassis type Mini PC
Product colour Black
Country of origin China
Performance
Product type PC
Trusted Platform Module (TPM) version 2.0
Trusted Platform Module (TPM) Yes
Software
Operating system installed Windows 11 IoT Enterprise
Operating system architecture 64-bit
Weight & dimensions
Width 188 mm
Depth 188 mm
Height 47.5 mm
Weight 1.9 kg
Package width 371 mm
Package depth 268 mm
Package height 122 mm
Package weight 12.3 kg
Packaging content
Display included No
View full details
