Vivolink VLUSBCPOWER control processor

• Supports USB PD 3.1 protocol
• Injects up to 140W charging for USB host. Max total cable length in + out = 7 meters
• Switchable power for USB-C out (15w)
• DP Alt mode w/ 4K@60Hz 4:4:4 video in and output
• Up to 10Gb USB 3.2 Gen2 data transfer rate

USB-C Power Injector supports up to 140W Charging. The charging requires a USB-C PD charger (not included).
Please order PD charger separately: VLUSBCPWR100
Supports DP Alt mode 4K@60Hz 4:4:4 video in / Output
Injects up to 140W charging for USB host. Max total cable length in + out = 7 meters
we recommend Max 2 meter on PC side and 3 meter og Device side.
The USB-C connector in and output are with hole for UBC-C cables with locking screw
we recommend Vivolink PROUSBCMMS
This injector occupies only one Tier in the USB connection.
