Vivolink VLSPMTC60WT loudspeaker 2-way White Wired 35 W
Vivolink VLSPMTC60WT loudspeaker 2-way White Wired 35 W
SKU:VLSPMTC60WT
50 in stock
Couldn't load pickup availability
Delivery & lead times
Delivery & lead times
Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.
Buying 5 or more? Volume pricing
Buying 5 or more? Volume pricing
We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.
Returns & warranty
Returns & warranty
See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.
- Transformer: 20W-15W-10W-8 Ohm/100V 35 Watt 6.5”
- 100V input
- Power input: 70 Watts
- Frequency Response:50Hz-20kHz
- Sensitivity(1M,1W): 89dB
- Woofer: 6.5" Tweeter: 0.5"
- Speaker dimension: 224x92mm
- Speaker set (2pcs)
Speaker, White, 35W, 6.5" With Crossover, Speaker set (2pcs) RMS35W
Typical installations:
Meeting rooms for ceiling mount.
Speaker dimension: 224x92mm.
The different tappings decide how many speakers can be connected to amplifier when using 100V commercial amplifier. Different tappings is for installers to connect different speaker qty and in different amplifiers.
The power of the total speaker installed should match the power of the amplifier.
Example, the rated power of amplifier is 300 watts, if you want to install 20 pcs speaker, then you can connect to 10 Watts tappings and 15 Watts tappings. . 10 x 20 = 200 watts, 15x20=300 watts.
30 watts tapping is for speaker qty you can connect is below 10 pcs
| Loudspeakers | |
|---|---|
| Speaker type | 2-way |
| Audio output channels | 2.0 channels |
| Speaker placement | Ceiling-mountable |
| Number of drivers | 1 |
| Tweeter | Yes |
| Tweeter diameter (imperial) | 1.27 cm (0.5") |
| Woofer | Yes |
| Woofer diameter (imperial) | 16.5 cm (6.5") |
| Audio | |
|---|---|
| RMS rated power | 35 W |
| Impedance | 8 Ω |
| Performance | |
|---|---|
| Product colour | White |
| Recommended usage | Home |
| Housing material | Plastic |
| Amplifier | |
|---|---|
| Amplifier | No |
| Ports & interfaces | |
|---|---|
| Connectivity technology | Wired |
| Bluetooth | No |
| Connector(s) | Speaker terminals |
| Power | |
|---|---|
| AC input voltage | 100 V |
| Transformer taps | 10 W |
| Weight & dimensions | |
|---|---|
| Width | 225 mm |
| Depth | 225 mm |
| Height | 92 mm |
| Weight | 3 kg |
| Diameter | 22.4 cm |
| Packaging data | |
|---|---|
| Package width | 250 mm |
| Package depth | 250 mm |
| Package height | 220 mm |
| Package weight | 3.49 kg |
| Other features | |
|---|---|
| Connector contacts plating | Bronze/Gold |
| Magnetically shielded | Yes |
| Input voltage | 100 V |
| Quick installation guide | Yes |
| Housing colour | White |
| Speaker weight | 3 kg |
