Vivolink VLHDMIEXTHDB2.0-R AV extender AV transmitter & receiver Black
Vivolink VLHDMIEXTHDB2.0-R AV extender AV transmitter & receiver Black
SKU:VLHDMIEXTHDB2.0-R
Low stock: 1 left
Couldn't load pickup availability
Delivery & lead times
Delivery & lead times
Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.
Buying 5 or more? Volume pricing
Buying 5 or more? Volume pricing
We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.
Returns & warranty
Returns & warranty
See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.
- AV transmitter & receiver 4096 x 2160 pixels Black
- Maximum transfer distance: 70 m
- Wired DC-in jack
Receiver HDMI 2.0 18Gbps,Bi-directional IR, RS232 and CEC, one PSU, HDMI 1.4 and HDCP2.2 compliant
Typical installation:
This receiver can be used for VLHDMIMAT4X431 and is alternative for VLHDMIMAT4X431-R
Function:
HDMI 2.0 receiver
Point to point,Tx to Rx for 70m@1080P,40m 4K@60Hz 4:4:4
Key features:
Full HDMI 2.0 compliant
18 Gbps bandwidth
Slim 4K HDBT extender.
Two way POC
Support Bi-directional IR and RS232
HDCP2.2 compliant
| Features | |
|---|---|
| Type | AV transmitter & receiver |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5e |
| Maximum transfer distance | 70 m |
| RS-232 pass-through | Yes |
| CEC pass-through | Yes |
| IR pass-through | Yes |
| HDCP pass-through | Yes |
| Wall mountable | Yes |
| HDCP & EDID bypass | Yes |
| Remote control type | IR + RS232 |
| Supported video modes | 3840p |
| LED indicators | Yes |
| Bandwidth | 18 Gbit/s |
| Product colour | Black |
| HDBaseT certified | Yes |
| Ports & interfaces | |
|---|---|
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| HDMI version | 2.0 |
| Number of HDMI outputs | 1 |
| HDMI in | 1 |
| RS-232 output ports | 1 |
| RS-232 input ports | 1 |
| Video out | 1 |
| Video in | 1 |
| 3.5 mm (1/8-inch) out | Yes |
| Serial ports quantity | 1 |
| Remote (IR) output | 1 |
| Remote (IR) input | 1 |
| Serial interface type | RS-232 |
| DC-in jack | Yes |
| Power | |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (transmitter) (max) | 3.5 W |
| Power consumption (receiver) (max) | 3.5 W |
| External power adapter | Yes |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | -10 - 50 °C |
| Weight & dimensions | |
|---|---|
| Width | 184 mm |
| Depth | 161 mm |
| Height | 126 mm |
| Weight | 153 g |
| Packaging data | |
|---|---|
| Package width | 184 mm |
| Package depth | 161 mm |
| Package height | 126 mm |
| Package weight | 400 g |
| Packaging content | |
|---|---|
| AC adapter included | Yes |
| Cables included | RS-232 |
| Included power plug types | EU |
| Mounting brackets included | Yes |
| IR receiver included | No |
| IR blaster included | No |
| Technical details | |
|---|---|
| Audio support | Yes |
