Vision

Vision HDMI-over-IP Transmitter AV transmitter Black

Vision HDMI-over-IP Transmitter AV transmitter Black

Regular price £101.21 GBP
Regular price Sale price £101.21 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

SKU:TC-HDMIIPTX/3

Low stock: 6 left

  • Distributes HDMI via a network
  • H.265 compression
  • One-to-One directly over a LAN or directly
  • One-to-Many over LAN
  • IR Pass-through
  • USB 1.1 transmission
92 x 67 x 168mm, 150g, Metal, Black, CAT6, 1920 x 1200, 6.75Gbps, 20 - 60000Hz, 100 - 240V

The TC-HDMIIP/3 converts HDMI signal into TCP/IP packets for transmission over a standard LAN network. With no visible loss of video quality it is perfect for corporate and digital signage applications.

Beware of cheap alternatives that flood your network!

USB Over Network
It can support USB version 1.1 from the transmitter to all receivers. Each receiver has two USB ports for adding flexibility. This is for USB peripherals like keyboard, mice, but not applications that demand high bandwidth like interactive displays.

Scalable
Transmitters and receivers sold separately so you can scale your system.

Advanced EDID Copy
A reset button restores EDID to default, or for advanced applications holding either of the reset buttons down will copy the display EDID to the transmitter.

One to Many
Need to display one source on many screens? This product multi-casts, so you can have one transmitter for the source, and over 100 x receivers can sit on the network – one for each display. Only one transmitter per network.

Point to Point without LAN
Connect one transmitter directly to a receiver and completely bypass a network. This will work with a standard CAT6 cable up to 150 m (492 ft) on a high quality cable.

Maximum Length
When using a LAN the signal will be repeated by each node on the network, resulting in unlimited length.

HD
Fully HDCP 1.4 compliant, it supports resolutions up to 1920 x 1200 @ 60 Hz.

Audio
Digital audio which is encoded on the HDMI signal is transmitted.

IR Pass-Through
Control the source device from the display with the IR pass-through. An IR blaster and receiver cable is included, and it supports standard 20-60 kHz IR signals.

Plug and Play
EDID (extended display identification data) is automatically passed through. Just connect everything together and it will work immediately.

H.265 Compression
Video is compressed using the H.265 protocol. Images are full colour with smooth motion.

LAN Protocols
Despite using the standard IP protocols you don’t need to be a network engineer. All end points must be on the same subnet… that’s all you need to know. For best results use a stand-alone network for this system.

Dual-Power
This product requires a power supply for each transmitter and receiver. It does not use PoE.

Unmanaged Switch
Many video-over-IP solutions require a managed switch so that IGMP snooping can be enabled, but in this case no advanced switch setup is required. A low cost unmanaged switch can be used.

Multiple Sources
If you need more than one source to be distributed over one physical LAN you can use Virtual LANs to separate the topologies. The systems are kept separate and cannot be used as a matrix. A DHCP switch assigns IP addresses to each end point and is used to create the vLANs.

Auto Standby
If the input is shut off the display will be allowed to go to sleep.

Not Backward Compatible
This version uses a Sigmastar chipset and is not compatible with the previous v2 product which uses a HiSilicon chipset.

Features
Product colour Black
HDCP version 1.4
Bandwidth 6.75 Gbit/s
HDCP Yes
Supported graphics resolutions 1920 x 1200 (WUXGA)
Video compression formats H.265
Cable length 1.5 m
Colour depth 12 bit
IR pass-through Yes
Maximum refresh rate 60 Hz
Cable types supported Cat5e, Cat6
Maximum resolution 1920 x 1200 pixels
Type AV transmitter
Ports & interfaces
USB connector type USB Type-A, USB Type-B
RJ-45 input ports 1
Connectivity technology Wired
Power
AC input frequency 50 / 60 Hz
AC input voltage 100 - 240 V
Operational conditions
Operating temperature (T-T) 10 - 50 °C
Operating relative humidity (H-H) 20 - 90%
Weight & dimensions
Transmitter weight 150 g
Transmitter dimensions (WxDxH) 92 x 67 x 168 mm
Weight 150 g
Height 168 mm
Depth 67 mm
Width 92 mm
Technical details
Compliance certificates RoHS
