Viewsonic

Viewsonic PA503W data projector Standard throw projector 3800 ANSI lumens DMD WXGA (1280x800) White

Viewsonic PA503W data projector Standard throw projector 3800 ANSI lumens DMD WXGA (1280x800) White

£399.23 GBP
£399.23 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

PA503W

Low stock: 8 left

  • Presentation Standard throw projector White
  • DMD 3800 ANSI lumens
  • Lamp 5000 h
  • WXGA (1280x800) 22000:1
  • Screen size compatibility: 762 - 7620 mm (30 - 300") Number of colours: 1.07 billion colours
  • Focus: Manual Zoom capability
  • Built-in speaker(s) 2 W
  • AC 260 W
3600 Lumen, DLP, WXGA, 16:9, 30-300", 100-240V, 50/60Hz, 396x110x218mm, 2.2 kg, White

Description

The ViewSonic PA503W price-performance projector features 3,600 lumens, native WXGA 1280x800 resolution, and an intuitive, user-friendly design. Exclusive SuperColor technology offers a wider color range for lifelike image projection. The PA503w also features extensive connectivity including HDMI, 2 x VGA in, Composite Video, 1 x VGA output, and Audio in/out. An energy-saving SuperEco feature reduces power consumption by up to 70%, and extends the lamp life by up to 10,000 hours. With advanced audiovisual features, flexible connectivity options, and an affordable price, the PA503W is ideal for use in education and small business environments.

Projector
Projector brightness 3800 ANSI lumens
Projection technology DMD
Projector native resolution WXGA (1280x800)
Contrast ratio (typical) 22000:1
Screen size compatibility 762 - 7620 mm (30 - 300")
Projection distance 1 - 10.98 m
Number of colours 1.07 billion colours
Vertical scan range 23 - 120 Hz
Horizontal scan range 15 - 102 kHz
Matrix size 1.65 cm (0.65")
Keystone correction, vertical -40 - 40°
Light source
Light source type Lamp
Service life of light source 5000 h
Service life of light source (economic mode) 15000 h
Lamp power 200 W
Lamps quantity 1 lamp(s)
Lens system
Focus Manual
Focal length range 22 - 24.1 mm
Aperture range (F-F) 2.56 - 2.68
Zoom capability Yes
Zoom ratio 2.0:1
Throw ratio 1.55-1.7
Offset 100%
Video
Analog signal format system NTSC, PAL, SECAM
Supported video modes 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Supported graphics resolutions 640 x 480 (VGA), 1920 x 1080 (HD 1080)
Ports & interfaces
VGA (D-Sub) ports quantity 3
HDMI ports quantity 1
HDMI connector type Full-size
HDMI version 1.4
Composite video in 1
DVI port No
Mini-USB 2.0 ports quantity 1
Serial interface type RS-232
PC Audio in Yes
PC Audio out Yes
Mobile High-Definition Link (MHL) No
AC (power) in Yes
Network
Smart TV No
Ethernet LAN No
Wi-Fi No
Storage
Card reader integrated No
Features
Interactive No
Noise level 31 dB
Noise level (economic mode) 27 dB
HDCP Yes
On Screen Display (OSD) Yes
On Screen Display (OSD) languages Arabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Indonesian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese
Number of OSD languages 22
Multimedia
Built-in speaker(s) Yes
RMS rated power 2 W
Design
Product type Standard throw projector
Market positioning Presentation
Product colour White
Placement Desktop, Ceiling
Display
Built-in display No
Power
Power source AC
Power consumption (typical) 260 W
Power consumption (standby) 0.5 W
AC input voltage 100-240 V
AC input frequency 50 - 60 Hz
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Weight 2.22 kg
Width 294 mm
Depth 218 mm
Height 110 mm
Package width 365 mm
Package depth 300 mm
Package height 188 mm
Package weight 3.24 kg
Packaging content
Remote control included Yes
Manual Yes
Cables included AC, VGA
Logistics data
Products per master (outer) case 1 pc(s)
Pallet gross height 2.21 m
Pallet gross width 90 cm
Pallet gross length 74 cm
Harmonized System (HS) code 8528620000
