Ubiquiti Networks
Regular price
£1,182.14 GBP
Regular price
Sale price
£1,182.14 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
SKU:USW-PRO-MAX-48-POE
44 in stock
- Etherlighting™ ports that illuminate to indicate port location, speed/link, and native VLAN/network*
- (16) 2.5 GbE ports including (8) PoE+ and (8) PoE++
- (32) GbE ports including (24) PoE+ and (8) PoE++
- (4) 10G SFP+ ports
- DC power backup ready
- 720W total PoE availability
- Managed with UniFi Network 8.0.24 and later
720W, 32 x GbE RJ45, 16 x 1/2.5 GbE RJ45, 4 x 10G SFP+, 224 Gbps, 1.3" touchscreen, SGCC steel, 442.4 x 400 x 44 mm (17.4 x 15.7 x 1.7")
A 48-port, Layer 3 Etherlighting™ switch with 2.5 GbE and PoE++ output.
| Management features |
|---|
| Switch layer |
L3 |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Basic switching RJ-45 Ethernet ports type |
2.5G Ethernet (100/1000/2500) |
| Gigabit Ethernet (copper) ports quantity |
32 |
| 2.5G Ethernet (copper) ports quantity |
16 |
| 10G Ethernet (copper) ports quantity |
4 |
| Installed SFP+ modules quantity |
4 |
| Power connector |
AC/DC |
| Network |
|---|
| 10G support |
Yes |
| VLAN support |
Yes |
| Data transmission |
|---|
| Switching capacity |
224 Gbit/s |
| Throughput |
112 Gbit/s |
| Design |
|---|
| Rack mounting |
Yes |
| Stackable |
Yes |
| Product colour |
Grey |
| Housing material |
Steel |
| Reset button |
Yes |
| LED indicators |
Link, Network, Speed, Status |
| Backlight display |
Yes |
| Display type |
LCM |
| Certification |
CE, FCC, IC |
| Performance |
|---|
| Minimum system requirements |
UniFi Network: Version 8.0.24 and later |
| Technical details |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Power |
|---|
| Power source |
AC/DC |
| Power supply included |
Yes |
| Redundant power supply (RPS) support |
Yes |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (max) |
100 W |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) ports quantity |
16 |
| Power over Ethernet plus (PoE+) ports quantity |
16 |
| Power over Ethernet 4PPoE (PoE++) ports quantity |
16 |
| Power over Ethernet (PoE) voltage |
57 V |
| Power over Ethernet (PoE) power per port |
15.4 W |
| Total Power over Ethernet (PoE) budget |
720 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-5 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Width |
442.4 mm |
| Depth |
400 mm |
| Height |
44 mm |
| Weight |
6.2 kg |
| Sustainability |
|---|
| Sustainability certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Sustainability compliance |
Yes |
| Packaging data |
|---|
| Cables included |
Power |
| Manual |
Yes |
| Rack mount kit |
Yes |
