4x 2.5/5/10G RJ-45, 2x 1/10 SFP+, 802.3bt PoE++, 40 W, 120 Gbps, 165 x 268.1 x 31.8 mm, 1.3 kg
Powerful Enterprise Switch Models The UniFi Switch delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. Its auto-sensing PoE ports deliver up to 60W of power per port.
10 Gbps Deployment Example Multiple switches connect via SFP+ to the UniFi Switch 16 XG. One UniFi Switch XG 6POE delivers data and 802.3bt PoE++ to multiple APs, the UniFi BaseStation XG, model UWB-XG, and the UniFi AP XG, model UAP-XG.
Multiple switches are daisy-chained through their SFP+ interfaces.
Convenient PoE++ Support The UniFi Switch features auto-sensing IEEE 802.3af/at/bt PoE to power multiple devices on the network.
10G High-Capacity Links The UniFi Switch offers maximum performance and low latency as an aggregation switch. For fiber connectivity, it features 2 SFP+ ports. For CAT 6/5e cable connectivity, the US-XG-6-POE offers 4 1/2.5/5/10Gbps RJ45 ports.
Seamless Integration A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.
