• Ubiquiti UniFi US-XG-6POE network switch, grey
1 6

Ubiquiti Networks

Ubiquiti UniFi US-XG-6POE network switch Managed 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Grey

Ubiquiti UniFi US-XG-6POE network switch Managed 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Grey

US-XG-6POE

£559.97 GBP£466.64 GBP
£0.00 GBP £559.97 GBP£466.64 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

Low stock: 5 left

Delivery & lead times

Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.

Buying 5 or more? Volume pricing

We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.

Returns & warranty

See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.

  • Managed
  • Basic switching RJ-45 Ethernet ports quantity: 4
  • 10G support
  • Switching capacity: 120 Gbit/s
  • 1U Rack mounting
  • Power supply included Power over Ethernet (PoE)
4x 2.5/5/10G RJ-45, 2x 1/10 SFP+, 802.3bt PoE++, 40 W, 120 Gbps, 165 x 268.1 x 31.8 mm, 1.3 kg

Powerful Enterprise Switch Models
The UniFi Switch delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. Its auto-sensing PoE ports deliver up to 60W of power per port.

10 Gbps Deployment Example
Multiple switches connect via SFP+ to the UniFi Switch 16 XG. One UniFi Switch XG 6POE delivers data and 802.3bt PoE++ to multiple APs, the UniFi BaseStation XG, model UWB-XG, and the UniFi AP XG, model UAP-XG.

Multiple switches are daisy-chained through their SFP+ interfaces.

Convenient PoE++ Support
The UniFi Switch features auto-sensing IEEE 802.3af/at/bt PoE to power multiple devices on the network.

10G High-Capacity Links
The UniFi Switch offers maximum performance and low latency as an aggregation switch. For fiber connectivity, it features 2 SFP+ ports. For CAT 6/5e cable connectivity, the US-XG-6-POE offers 4 1/2.5/5/10Gbps RJ45 ports.

Seamless Integration
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.

Management features
Switch type Managed
Ports & interfaces
SFP+ module slots quantity 2
Basic switching RJ-45 Ethernet ports type 10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity 4
Network
Link aggregation Yes
Full duplex Yes
Port mirroring Yes
10G support Yes
Networking standards IEEE 802.3bt
Data transmission
Jumbo frames support Yes
Switching capacity 120 Gbit/s
Security
Security algorithms 802.1x RADIUS
Design
Certification CE, FCC, IC
LED indicators Yes
Product colour Grey
Form factor 1U
Rack mounting Yes
general_information_attribute_container_name
attribute_product_family_name UniFi
Power
Power consumption (max) 40 W
DC input voltage 44 - 57 V
Power supply included Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port 60 W
Power over Ethernet (PoE) Yes
Operational conditions
Operating relative humidity (H-H) 5 - 95%
Operating temperature (T-T) -5 - 45 °C
Weight & dimensions
Weight 1.3 kg
Height 31.8 mm
Depth 165 mm
Width 268.1 mm
Packaging data
Manual Yes
Logistics data
Harmonized System (HS) code 85176990
