(1) 10 GbE PoE+++ input port for power / SFP+ port combo (57W PoE availability with PoE+++ input / 37W PoE availability with PoE++ input / 12W PoE availability with PoE+ input)
196W PoE availability with optional AC power adapter
8x 2.5 GbE PoE++, 1x 10G SFP+ or 10/5/2.5/1 GbE RJ45 combination port, 60W PoE++, 60 Gbps, white
Flexible, 8-port 2.5 GbE PoE++ switch with a 10 GbE RJ45/SFP+ combination uplink port that can be powered with PoE+++ or an AC power adapter*.
*AC power adapter sold separately.
Management features
Switch type
Managed
Switch layer
L2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity
8
10G Ethernet (copper) ports quantity
1
SFP+ module slots quantity
1
Power connector
DC-in jack
Network
10G support
Yes
Port mirroring
Yes
Rate limiting
Yes
Ethernet LAN data rates
10,100,1000,2500 Mbit/s
Broadcast storm control
Yes
Flow control support
Yes
Data transmission
Switching capacity
60 Gbit/s
Throughput
30 Gbit/s
Forwarding rate
44.64 Mpps
Jumbo frames support
Yes
Security
Loop protection
Yes
Multicast features
Multicast support
Yes
Design
Form factor
Desktop/Wall-Mounting
Product colour
White
Housing material
Polycarbonate (PC)
Reset button
Yes
LED indicators
Activity, Link, PoE, Power, Status
DIN rail mounting
Yes
Wall mountable
Yes
general_information_attribute_container_name
attribute_product_family_name
UniFi
Technical details
Compliance certificates
CE, Federal Communications Commission (FCC), Industry Canada (IC)
