SKU:USW-FLEX-2.5G-8-UK
29 in stock
- Managed L2
- Basic switching RJ-45 Ethernet ports quantity: 8
- 10G support
- MAC address table: 4000 entries Switching capacity: 60 Gbit/s
- Desktop/Wall-Mounting
- PoE/USB Power supply included Power over Ethernet (PoE)
8x 2.5 GbE RJ45, 1x 10 GbE RJ45, 1x 10G SFP+, 60 Gbps, USB Type-C, 5V DC, 3A, 395 g
Flexible, 8-port 2.5 GbE switch with a 10 GbE RJ45/SFP+ combination uplink port that can be powered with a USB-C or PoE+ adapter.
| Management features |
|---|
| Switch type |
Managed |
| Switch layer |
L2 |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
2.5G Ethernet (100/1000/2500) |
| 2.5G Ethernet (copper) ports quantity |
8 |
| 10G Ethernet (copper) ports quantity |
1 |
| SFP+ module slots quantity |
1 |
| Power connector |
DC-in jack |
| Network |
|---|
| 10G support |
Yes |
| Port mirroring |
Yes |
| Rate limiting |
Yes |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| Broadcast storm control |
Yes |
| Flow control support |
Yes |
| VLAN support |
Yes |
| Number of VLANs |
256 |
| Data transmission |
|---|
| MAC address table |
4000 entries |
| Switching capacity |
60 Gbit/s |
| Throughput |
30 Gbit/s |
| Forwarding rate |
45 Mpps |
| Jumbo frames support |
Yes |
| Security |
|---|
| Loop protection |
Yes |
| Multicast features |
|---|
| Multicast support |
Yes |
| Design |
|---|
| Form factor |
Desktop/Wall-Mounting |
| Product colour |
White |
| Housing material |
Polycarbonate (PC) |
| Reset button |
Yes |
| LED indicators |
Activity, Link, PoE, Power, Status |
| DIN rail mounting |
Yes |
| Wall mountable |
Yes |
| general_information_attribute_container_name |
|---|
| attribute_product_family_name |
UniFi |
| Technical details |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Power |
|---|
| Power source |
PoE/USB |
| Power supply included |
Yes |
| Input voltage |
4.8-5.2 / 44-57 V |
| Power consumption (max) |
14 W |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) type supported |
PoE+ |
| Power over Ethernet plus (PoE+) ports quantity |
1 |
| Power over Ethernet (PoE) voltage |
57 V |
| Power over Ethernet (PoE) power per port |
15.4 W |
| Total Power over Ethernet (PoE) budget |
196 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-20 - 45 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Width |
212.9 mm |
| Depth |
76 mm |
| Height |
33.5 mm |
| Weight |
395 g |
