Ubiquiti Networks

Ubiquiti UniFi EAV-XG-24-PoE (2150W) Managed L2/L3 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Black

Ubiquiti UniFi EAV-XG-24-PoE (2150W) Managed L2/L3 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Black

£3,712.73 GBP
£3,712.73 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

EAV-XG-24-POE

19 in stock

  • Managed L2/L3
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 25 Console port: RJ-45
  • 10G support
  • MAC address table: 32000 entries Switching capacity: 1280 Gbit/s
  • 1U Rack mounting
  • AC Power supply included Power over Ethernet (PoE)
Enterprise Audio/Video XG 24 PoE, 1280 Gbps, 1 GbE RJ45, 24x 10 GbE RJ45 (All PoE+++), 4x 100G QSFP28, SMA, Rack Mount (1U, Full-Depth), 2150W

Enterprise Audio/Video switch with (24) 10G PoE+++ ports and (4) 100G QSFP28 uplinks. Supports PTP timing, SMPTE ST 2110, SDVoE, and AES67 audio, with a high-precision OCXO clock and optional GPS grandmaster input (SMA) for deterministic media synchronization. Includes Etherlighting™ support.

Management features
Switch type Managed
Switch layer L2/L3
Quality of Service (QoS) support Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 25
Basic switching RJ-45 Ethernet ports type 10G Ethernet (100/1000/10000)
Gigabit Ethernet (copper) ports quantity 1
10G Ethernet (copper) ports quantity 24
Fiber ports quantity 4
Fiber optic connector QSFP28
Console port RJ-45
QSFP28 ports quantity 4
Power connector AC-in jack
Network
Networking standards IEEE 802.1x
10G support Yes
Port mirroring Yes
IPv4 routes 512
Rate limiting Yes
Ethernet LAN data rates 100,1000,10000,2500,5000,10 Mbit/s
Broadcast storm control Yes
Flow control support Yes
VLAN support Yes
Virtual LAN features Voice VLAN
Number of VLANs 1000
Data transmission
MAC address table 32000 entries
Switching capacity 1280 Gbit/s
Throughput 640 Gbit/s
Forwarding rate 810 Mpps
Static route Yes
Jumbo frames support Yes
Packet buffer memory 8 MB
Security
DHCP features DHCP server, DHCP relay, DHCP guarding, DHCP snooping
Access Control List (ACL) IPv4 entries 256
IGMP snooping Yes
Loop protection Yes
Multicast features
Multicast support Yes
Design
Rack mounting Yes
Form factor 1U
Product colour Black
Housing material SGCC
Reset button Yes
LED indicators Fan, Power, LAN
Display type LCM
general_information_attribute_container_name
attribute_product_family_name UniFi
Technical details
Compliance certificates CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)
Power
Power source AC
Power supply included Yes
Number of power supply units 2
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Power consumption (max) 2400 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) type supported PoE+, PoE++ (4PPoE), PoE+++
Power over Ethernet (PoE+++) ports quantity 24
Operational conditions
Operating temperature (T-T) -5 - 40 °C
Operating relative humidity (H-H) 10 - 90%
Heat dissipation 512 BTU/h
Weight & dimensions
Width 442.4 mm
Depth 480 mm
Height 43.7 mm
Weight 9.85 kg
Packaging data
Cables included AC
Rack mount kit Yes
