Ubiquiti UniFi Dream Machine Pro Max Managed 2.5G Ethernet (100/1000/2500) 1U Grey

Ubiquiti UniFi Dream Machine Pro Max Managed 2.5G Ethernet (100/1000/2500) 1U Grey

£519.22 GBP
£519.22 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

UDM-PRO-MAX-UK

38 in stock

  • Enhanced computing power and memory for 2x the UniFi device and client capacity of Dream Machine Pro/SE
  • Includes full UniFi application suite for device management
  • 5 Gbps routing with IDS/IPS
  • (1) 10G SFP+*, (8) GbE RJ45 LAN ports
  • (1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports
  • (2) 3.5" NVR HDD bays with RAID data protection
  • Built-in 128 GB SSD for NVR detection recordings
  • 1.3" touchscreen
10 Gbps SFP+ LAN / WAN, 8x GbE RJ45 LAN, 2.5 GbE RJ45 WAN, 2x 3.5" NVR HDD bays, 128 GB SSD, 1.3" screen, Aluminium CNC, SGCC steel, UK

Professional-grade, rack-mount Cloud Gateway with 10 Gbps performance, multi-WAN load balancing, and two NVR drive bays designed for large-scale, multi-application UniFi sites.

Management features
Switch type Managed
Quality of Service (QoS) support Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 9
Basic switching RJ-45 Ethernet ports type 2.5G Ethernet (100/1000/2500)
Gigabit Ethernet (copper) ports quantity 1
2.5G Ethernet (copper) ports quantity 1
SFP+ module slots quantity 2
Power connector DC-in jack
Network
10G support Yes
Policy-based routing Yes
Ethernet LAN data rates 10,100,1000,2500 Mbit/s
VLAN support Yes
Virtual LAN features IP subnet–based VLAN
Data transmission
Throughput 5 Gbit/s
Security
DHCP features DHCP relay, DHCP server
IGMP proxy Yes
Design
Rack mounting Yes
Stackable No
Form factor 1U
Product colour Grey
Housing material Aluminium, Galvanized steel
Reset button Yes
LED indicators Activity, Error, Link, Ready
Display type LCM
general_information_attribute_container_name
attribute_product_family_name UniFi
Performance
Built-in processor Yes
Processor model ARM Cortex-A57
Processor frequency 2000 MHz
Memory type DDR4-SDRAM
Internal memory 8000 MB
Flash memory 32000 MB
Technical details
Compliance certificates CE, Federal Communications Commission (FCC), Industry Canada (IC)
Power
Power source AC/DC
Power supply included Yes
Redundant power supply (RPS) support Yes
Number of power supply units 1
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
DC input voltage 12 V
Input current 2 A
Power consumption (max) 60 W
Power plug type Type G
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) -10 - 40 °C
Operating relative humidity (H-H) 5 - 95%
Weight & dimensions
Width 442.4 mm
Depth 285.6 mm
Height 43.7 mm
Weight 4.7 kg
Sustainability
Sustainability compliance Yes
Packaging data
Cables included AC
Rack mount kit Yes
User guide Yes
