Desktop, 2x 3.5" drive bays, 2.5 GbE RJ45 (2.5G/1G/100M/10M), 5 Gbps USB-C, PoE++, Quad-Core ARM Cortex-A55 at 1.7 GHz, Bluetooth 4.1, 1.47" color LCM
UniFi Network Attached Storage with (2) 3.5" HDD bays, 2.5 GbE networking, USB-C connectivity, and an included PoE++ adapter, all in a compact footprint.
Storage
Storage drives installed
No
Number of storage drives supported
2
Installed storage drive type
No
Supported storage drive types
HDD
Storage drive size
3.5"
Storage drive sizes supported
3.5"
RAID support
Yes
RAID levels
1
Hot-swap drive bays
No
Processor
Processor manufacturer
ARM
Processor family
Cortex-A
Processor model
Cortex-A57
Processor frequency
1.7 GHz
Processor cores
4
Processor architecture
ARM Cortex-A57
Memory
Internal memory
4 GB
Network
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000,2500 Mbit/s
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
USB port
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
Design
Chassis type
Desktop
Product colour
White
Housing material
Polycarbonate (PC)
LED indicators
Status, System
Built-in display
Yes
Display type
LCM
Performance
Type
NAS
Backup function
Yes
Web-based management
Yes
Reset button
Yes
Software
Other operating systems supported
Android, iOS
Power
Power supply location
External
Power consumption (max)
60 W
Weight & dimensions
Width
129 mm
Depth
135 mm
Height
223.7 mm
Weight
1.3 kg
Technical details
Compliance certificates
CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)
