Ubiquiti Networks
Ubiquiti UISP Pro Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White
Ubiquiti UISP Pro Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White
SKU:UISP-S-PRO
Regular price
£373.68 GBP£311.40 GBP
Regular price
£0.00 GBP
Sale price
£373.68 GBP£311.40 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Low stock: 10 left
Couldn't load pickup availability
Delivery & lead times
Delivery & lead times
Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.
Buying 5 or more? Volume pricing
Buying 5 or more? Volume pricing
We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.
Returns & warranty
Returns & warranty
See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.
- (24) GbE RJ45 ports, including (16) with 27V passive PoE output
- (4) 10G SFP+ ports
- 220W (27V) total PoE availability, 15W/port (2-pair) / 30W/port (4-pair)
- 1.3" LCM color touchscreen
- Easy Bluetooth setup with the UISP Mobile app
UISP Switch Pro, 1.3" LCM, 24x GbE RJ45, 4x 10G SFP+
A 24-port, Layer 2 PoE switch designed for ISP networks.
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Ports & interfaces | |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 4 |
| Network | |
|---|---|
| Over-the-air bluetooth access | Yes |
| Data transmission | |
|---|---|
| Switching capacity | 128 Gbit/s |
| Throughput | 64 Gbit/s |
| Forwarding rate | 95.23 Mpps |
| Design | |
|---|---|
| Rack mounting | Yes |
| Stackable | No |
| Product colour | White |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC), Steel |
| LED indicators | Activity, Link, PoE, Speed |
| Display type | LCM |
| Certification | IC |
| general_information_attribute_container_name | |
|---|---|
| attribute_product_family_name | UISP |
| Technical details | |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Power | |
|---|---|
| Power source | AC/DC |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| DC input voltage | 18 - 27 V |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | Passive PoE |
| Power over Ethernet (PoE) voltage | 27 V |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 220 W |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
|---|---|
| Width | 442.4 mm |
| Depth | 267.5 mm |
| Height | 43.7 mm |
| Weight | 4 kg |
| Sustainability | |
|---|---|
| Sustainability certificates | CE, Federal Communications Commission (FCC) |
| Sustainability compliance | Yes |
| Packaging data | |
|---|---|
| Manual | Yes |
