• Ubiquiti UISP Horn, 19.5 dBi
1 5

Ubiquiti Networks

Ubiquiti UISP Horn network antenna Horn antenna 19.5 dBi

Ubiquiti UISP Horn network antenna Horn antenna 19.5 dBi

UISP-HORN

£168.10 GBP£140.08 GBP
£0.00 GBP £168.10 GBP£140.08 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

12 in stock

Delivery & lead times

Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.

Buying 5 or more? Volume pricing

We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.

Returns & warranty

See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.

  • High-isolation 30° horn antenna that covers a wide operating frequency range (5.15 - 6.875 GHz)
  • Low backlobes for device co-location
  • 15+ km PtMP link range
  • Die-cast, UV-stabilized polycarbonate enclosure for enhanced durability and weatherproofing
  • Pole-mountable antenna with a metal carrying handle
  • Two side latches for secure, snap-in radio connection
High-isolation, point-to-multipoint (PtMP) horn antenna that covers a wide operating frequency range (5.15 - 6.875 GHz)

The UISP® Horn is an efficient PtMP antenna that provides high isolation within congested environments by utilizing its wide operating frequency range. With the included WaveGuide adapter, this antenna can be easily attached to an airFiber 5XHD Radio (AF 5XHD), LTU Rocket , or airMAX Rocket Prism AC 5 GHz Radio (RP 5AC) to amplify their signal. The UISP Horn also has a latch on each side for secure, snap-in radio connection. Operation frequency may vary based on regional radio frequencies and regulations.

Performance
Antenna gain level (max) 19.5 dBi
Frequency band 5.15 - 6.875 GHz
Vertical beam width 25°
Horizontal beam width 30°
Features
Antenna type Horn antenna
Polarization Dual polarization
International Protection (IP) code IPX6
Ultraviolet (UV) resistant Yes
Wind load 90
Survival wind speed 200 km/h
Mounting pipe 25 - 70 mm
Isolation 20 dB
Mounting Pole
Purpose Outdoor
Compatible products airFiber 5XHD Radio (AF 5XHD), LTU Rocket, or airMAX Rocket Prism AC 5 GHz Radio (RP 5AC)
Housing material Aluminium, Polycarbonate (PC)
Product colour White
Weight & dimensions
Width 224 mm
Depth 380 mm
Height 282 mm
Weight 3.06 kg
Packaging content
Mounting kit Yes
