Ubiquiti Networks

Ubiquiti UFiber WiFi6 GPON CPE Optical network unit (ONU)

Ubiquiti UFiber WiFi6 GPON CPE Optical network unit (ONU)

£94.92 GBP
£94.92 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

UF-WIFI6-US

11 in stock

  • 2x2, high-efficiency WiFi 6
  • 2.4 GHz band (2x2 MIMO) with a 300 Mbps radio rate
  • 5 GHz band (2x2 MU-MIMO and OFDMA) with a 1.2 Gbps radio rate
  • 2.4 Gbps max downstream line rate
  • 1.2 Gbps max upstream line rate
  • Establishes GPON links up to 20 km
  • Powerful Layer 2/3 management features
  • (1) GPON WAN port
  • (4) GbE RJ45 LAN ports
  • Powered with the included power adapter or passive PoE
  • Internal WiFi 6 (802.11ax) antennas
GPON, Wi-Fi 6, 4x RJ-45, SC/APC, PoE, 2.488 Gbps downstream, 1.244 Gbps upstream

High-performance WiFi 6 GPON CPE.
The UFiber WiFi6 GPON CPE (UF WiFi6) is a point-to-multipoint WiFi 6 device that creates high-speed GPON connections capable of reaching a 2.4 Gbps downstream rate and 1.2 Gbps upstream rate. The UF WiFi6 has (4) GbE RJ45 LAN ports and (1) GPON WAN port to connect a local fiber line. It also excels at establishing reliably strong, long-distance fiber links up to 20 kilometers, allowing you to extend your service range and build your customer base.

Design
Product type Optical network unit (ONU)
Product colour Black
LED indicators LAN, Power
Network
Networking standards IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
ITU standards G.984
Ethernet LAN data rates 1000 Mbit/s
Cabling technology 10/100/1000Base-T(X)
Switch layer L2+/L3
Upstream data rate 2488 Mbit/s
Downstream data rate 1244 Mbit/s
Transmission distance (max) 20 km
Tx wavelength (max) 1310 nm
Rx wavelength (max) 1490 nm
VLAN support Yes
Wireless LAN features
Wi-Fi Yes
Wi-Fi standards 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Antenna type Internal
Antenna gain level (max) 3 dBi
Management features
Reset button Yes
Security
Security algorithms AES, TKIP, WEP, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3
Ports & interfaces
Fiber ports quantity 1
Fiber optic connector SC
Ethernet LAN (RJ-45) ports 4
USB ports quantity 1
DC-in jack Yes
Power
Output voltage 5 V
Output current 3 A
Power consumption (max) 11 W
Technical details
Compliance certificates CE
Operational conditions
Operating temperature (T-T) -15 - 45 °C
Operating relative humidity (H-H) 10 - 90%
Weight & dimensions
Width 141.5 mm
Depth 140.8 mm
Height 31.6 mm
Weight 415 g
Packaging content
Quantity per pack 1 pc(s)
AC adapter included Yes
