Ubiquiti Networks

Ubiquiti Dream Machine Special Edition gateway/controller 1000 Mbit/s

Ubiquiti Dream Machine Special Edition gateway/controller 1000 Mbit/s

£443.34 GBP
£443.34 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

UDM-SE-UK

149 in stock

  • Includes full UniFi application suite for device management
  • 3.5+ Gbps routing with IDS/IPS
  • Integrated 8-port PoE/PoE+ switch
  • (1) 10G SFP+, (8) GbE RJ45 LAN ports including (2) PoE+, and (6) PoE
  • (1) 10G SFP+, (1) 2.5 GbE RJ45 WAN ports
  • 1.3" touchscreen
  • 128 GB SSD & 3.5" NVR HDD bay
8x LAN, WAN, PoE/PoE+, Bluetooth, 4 GB DDR4, 16 GB eMMC, 128 GB SSD

Enterprise-grade, rack-mount UniFi Cloud Gateway with full UniFi application support, 10 Gbps performance, and an integrated PoE switch.

Design
Product colour Stainless steel
Rack capacity 1U
Enclosure material Aluminum
Mounting type Rack mounting
LED indicators HDD, LAN
Certification CE, FCC, IC
Performance
Control display unit Yes
Processor family ARM Cortex
Processor manufacturer ARM
Processor model Cortex-A57
Built-in processor Yes
Processor frequency 1700 MHz
Number of processors installed 1
Internal memory type DDR4
SSD capacity 128 GB
Internal memory 4096 MB
Flash memory 16384 MB
Protocols
DHCP server Yes
Network
Ethernet LAN data rates 1000 Mbit/s
Networking standards IEEE 802.3af, IEEE 802.3at
Bluetooth Yes
Security
Firewall security Yes
VLAN support Yes
Ports & interfaces
SFP+ ports quantity 2
WAN connection Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports 8
Management features
Quality of Service (QoS) support Yes
Reset button Yes
Power
Input voltage 100 - 240 V
Input frequency 50/60 Hz
Input current 4.4 A
Power supply 240 W
Power over Ethernet (PoE) Yes
Weight & dimensions
Height 43.7 mm
Depth 285.6 mm
Width 442.4 mm
Weight 4.95 kg
Packaging content
Manual Yes
Operational conditions
Operating temperature (T-T) -10 - 40 °C
Operating relative humidity (H-H) 5 - 95%
Display
Display diagonal 3.3 cm (1.3")
Touchscreen Yes
