Ubiquiti Networks
Regular price
£341.45 GBP
Regular price
Sale price
£341.45 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
SKU:UDM-PRO-UK
133 in stock
- Includes full UniFi application suite for device management
- 3.5+ Gbps routing
- (1) 10G SFP+, (8) GbE RJ45 LAN ports
- (1) 10G SFP+, (1) GbE RJ45 WAN ports
- 1.3" touchscreen
- 3.5" HDD bay
8 x LAN GbE, 1 x WAN GbE, 1 x LAN SFP+, 1 x WAN SFP+, ARM Cortex-A57 1.7 GHz, 4 GB DDR4, 442.4 x 43.7 x 285.6 mm, 3.9 kg, UK
Enterprise-grade, rack-mount UniFi Cloud Gateway with full UniFi application support, 10 Gbps performance, and an integrated switch.
| WAN connection |
|---|
| Ethernet WAN |
Yes |
| DSL WAN |
No |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| SFP WAN |
Yes |
| Network |
|---|
| Ethernet interface type |
Fast Ethernet, Gigabit Ethernet |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Throughput |
3.5 Gbit/s |
| Management features |
|---|
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| Reset button |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
8 |
| WAN/Ethernet LAN ports quantity |
1 |
| SFP+ module slots quantity |
1 |
| DC-in jack |
Yes |
| Protocols |
|---|
| DHCP server |
Yes |
| Storage |
|---|
| Number of HDDs supported |
1 |
| HDD size |
3.5" |
| Technical details |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC) |
| Sustainability compliance |
Yes |
| Features |
|---|
| Built-in processor |
Yes |
| Processor model |
ARM Cortex-A57 |
| Processor frequency |
1700 MHz |
| Processor cores |
4 |
| Storage media |
eMMC |
| Flash memory |
16000 MB |
| Internal memory |
4096 MB |
| Internal memory type |
DDR4 |
| Design |
|---|
| Product colour |
White |
| Housing material |
Aluminium, Steel |
| LED indicators |
Yes |
| Built-in display |
Yes |
| Display type |
LCM |
| Touchscreen |
Yes |
| Display diagonal |
3.3 cm (1.3") |
| Power |
|---|
| Power consumption (max) |
33 W |
| Power supply |
50 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-10 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
|---|
| Width |
442.4 mm |
| Depth |
285.6 mm |
| Height |
43.7 mm |
| Weight |
3.9 kg |
| Packaging data |
|---|
| Cables included |
AC |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
