Ubiquiti Dream Machine Beast gateway/controller 10, 100, 1000, 2500, 10000, 5000 Mbit/s
Ubiquiti Dream Machine Beast gateway/controller 10, 100, 1000, 2500, 10000, 5000 Mbit/s
Regular price
£1,411.98 GBP
Regular price
Sale price
£1,411.98 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
SKU:UDM-BEAST
43 in stock
- 10,100,1000,2500,10000,5000 Mbit/s
- Control display unit Built-in processor 2100 MHz 16000 MB 128 GB
- Quality of Service (QoS) support
- Rack mounting
- Enclosure material: Aluminium/SGCC
- Grey
25 Gbps IPS/IDS, 7,500+ client, 1U, (2) 3.5" NVR HDD bays, 342 BTU/hr, 100W
Hyperscale-class Cloud Gateway delivering 25 Gbps IPS/IDS, 7,500+ client capacity, and the full UniFi application platform in one system.
| Design |
|---|
| Product colour |
Grey |
| Rack capacity |
1U |
| Enclosure material |
Aluminium/SGCC |
| Mounting type |
Rack mounting |
| LED indicators |
Activity, Error, Link, Ready |
| Performance |
|---|
| Control display unit |
Yes |
| Display type |
LCM |
| Processor family |
ARM Cortex |
| Processor manufacturer |
ARM |
| Built-in processor |
Yes |
| Processor frequency |
2100 MHz |
| Number of processors installed |
1 |
| SSD capacity |
128 GB |
| Internal memory |
16000 MB |
| Protocols |
|---|
| DHCP server |
Yes |
| Routing protocols |
BGP, OSPF |
| Network |
|---|
| Ethernet LAN data rates |
10,100,1000,2500,10000,5000 Mbit/s |
| Port aggregation |
Yes |
| Security |
|---|
| Network address translation (NAT) |
Yes |
| Firewall security |
Yes |
| Ports & interfaces |
|---|
| Console port |
RJ-45 |
| Number of console ports |
1 |
| SFP+ ports quantity |
2 |
| WAN connection |
Ethernet (RJ-45), SFP+ |
| Ethernet LAN (RJ-45) ports |
10 |
| Management features |
|---|
| Multicast support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Reset button |
Yes |
| Power |
|---|
| Power consumption (max) |
100 W |
| Input voltage |
100 - 240 V |
| Input frequency |
50/60 Hz |
| Input current |
3 A |
| DC input voltage |
12 V |
| Heat dissipation |
342 BTU/h |
| Power over Ethernet (PoE) |
No |
| Electrostatic Discharge (ESD) protection (air) |
8 kV |
| Electrostatic Discharge (ESD) protection (contact) |
4 kV |
| Electromagnetic (EMP) protection |
Yes |
| Electromagnetic (EMP) protection (air) |
8 kV |
| Electromagnetic (EMP) protection (contact) |
4 kV |
| Weight & dimensions |
|---|
| Height |
43.7 mm |
| Depth |
325 mm |
| Width |
442.4 mm |
| Weight |
5.5 kg |
| Packaging content |
|---|
| Cables included |
AC |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-10 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Technical details |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
