- Ultra Low-Light lmaging
- AI-ISP Powered
- Intelligent IR-White Lights
- High Definition
- Alarm IN/OUT Devices Integration
- People & Vehicle Attributes Analysis
- Human & Vehicle Classification
- Two-Way Audio
CMOS, 4 MP, 1/10000 s, F1.0, 112.5°/61.4°, 59 m, 360°, 0°-75°, 850 nm, 2688 x 1520, 30 fps, 50-60 Hz, CBR/VBR, H.264/H.265, 120 dB, Two-Way, 64 Kbps, 1 x RJ-45, MicroSD 512 GB, -30-60°C, 0-95%, 12V DC, 17.9 W, Metal, White, 111 x 81.4, 0.55 kg
See True Colors and Details in the Dark
Unveiling every detail in the dark, experiencing clarity and color as vivid as daylight — no extra fill lights needed.
Worry-Free Night Surveillance: Beyond IR & Full-Color
Eliminates general night vision issues like dark corners, glare, and color loss — enjoy worry-free nighttime monitoring.
See Vividly — Even No Extra Fill Lights Needed
Enables full-color imaging in low-light conditions without fill-in lighting, reducing both energy consumption and insect-triggered false alarms for a more eco-friendly solution.
People or Vehicle Triggered Intelligent IR-White Lights Reveal More in Total Darkness
In complete darkness with zero illumination, VIGI’s intelligent infrared-white lights will automatically activate white lights upon detecting people or vehicles, delivering vivid color imaging while deterring intruders.
Accurate Detection with Clear and Extended Vision
Ideal for Low-Light Conditions Where Colors and Details Matter
VIGI AI Detection Technology
People & Vehicle Attributes Analytics: Search and filter to people or vehicle of interest based on many different attributes, like hair length, topwear color, vehicle type, making post-event search faster and easier
Human & Vehicle Classification: Distinguish humans and vehicles from other objects, such as moving animals, falling leaves, changing lights, and receive more accurate event notifications
Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
| Performance |
|---|
| Type |
IP security camera |
| Placement supported |
Outdoor |
| Connectivity technology |
Wired |
| Auto pan mode |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Day/night mode |
Yes |
| Alarm input/output |
Yes |
| Dynamic range |
120 dB |
| Certification |
CE, NTRA, VCCI, KC, IC, BSMI, FCC, IP67, ONVIF |
| Design |
|---|
| Form factor |
Dome |
| Mounting type |
Ceiling/wall |
| Product colour |
White |
| Housing material |
Metal |
| International Protection (IP) code |
IP67 |
| Weatherproof |
Yes |
| Camera |
|---|
| Minimum illumination |
0.0005 lx |
| Angle of rotation |
360° |
| Lens viewing angle, horizontal |
112.5° |
| Lens viewing angle, vertical |
61.4° |
| Lens viewing angle, diagonal |
137° |
| Tilt angle range |
0 - 75° |
| Pan range |
0 - 360° |
| White balance |
Area white balance |
| Camera shutter type |
Electronic |
| Camera shutter speed |
1/3 - 1/10000 s |
| Number of Privacy masking areas |
4 |
| Panoramic camera |
|---|
| Sensor type (panoramic camera) |
CMOS |
| Signal-to-Noise Ratio (SNR) (panoramic camera) |
52 dB |
| Image sensor |
|---|
| Sensor type |
CMOS |
| Optical sensor size |
25.4 / 79 mm (1 / 79") |
| Progressive scan |
Yes |
| Lens system |
|---|
| Number of lenses |
1 |
| Detect distance |
59 m |
| Observe distance |
25 m |
| Recognize distance |
12 m |
| Fixed focus |
Yes |
| Identify distance |
6 m |
| Maximum aperture number |
1 |
| Fixed focal length |
2.8 mm |
| Night vision |
|---|
| Night vision |
Yes |
| Infra-red wavelength |
850 nm |
| Video |
|---|
| Maximum resolution |
2688 x 1520 pixels |
| Total megapixels |
4 MP |
| Video formats supported |
H.264, H.264+, H.265, H.265+ |
| Video compression formats |
H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions |
320 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 704 x 576, 848 x 480, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520 |
| Video recording |
Yes |
| Frame rate |
30 fps |
| Thermal frame rate (PAL) |
60 Hz |
| Thermal frame rate (NTSC) |
50 Hz |
| Video streaming |
Yes |
| Noise reduction |
Yes |
| Bit rate control |
Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Smart IR |
Yes |
| Highlight Compensation (HLC) |
Yes |
| Bit rate |
64 Kbit/s |
| Region of Interest (ROI) encoding |
Yes |
| Back Light Compensation (BLC) |
Yes |
| Image quality adjustment |
Brightness, Contrast, DNR, Saturation, Sharpness |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| Audio system |
2-way |
| Audio input channels |
2.0 channels |
| Audio output channels |
2.0 channels |
| Number of microphones |
1 |
| Built-in microphone |
Yes |
| Bit rate range |
256 - 6000 Kbit/s |
| Network |
|---|
| Ethernet LAN |
Yes |
| Networking standards |
IEEE 802.1x, IEEE 802.3at |
| Supported network protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP |
| Number of simultaneous live view channels |
3 channels |
| Live view |
Yes |
| Storage |
|---|
| Built-in HDD |
No |
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash) |
| Maximum memory card size |
512 GB |
| Cloud services supported |
FTP |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Microphone in |
Yes |
| Security |
|---|
| Alarm input channels |
1 |
| Alarm output channels |
1 |
| Password protection |
Yes |
| Password protection type |
User |
| Human and vehicle targets classification |
Yes |
| Digest authentication |
Yes |
| Mirror |
Yes |
| HTTPS encryption |
Yes |
| IP address filtering |
Yes |
| Motion sensor |
Yes |
| Intelligent Video Surveillance (IVS) system features |
Abandoned object, Abnormal sound detection, Intrusion, Line crossing detection, People counting, Region entrance detection, Region exiting detection, Scene change, Vehicle detection |
| Alert notification type |
E-mail, Push notification |
| Active tampering alarm |
Yes |
| Video motion detection |
Yes |
| Management features |
|---|
| Web-based management |
Yes |
| Web browser |
Yes |
| Cloud-managed |
Yes |
| Behavior analysis |
Audio exception detection, Object removal detection |
| Reset button |
Yes |
| Power |
|---|
| Power source type |
DC, PoE |
| AC input voltage |
12 V |
| Power consumption (typical) |
15.6 W |
| Power consumption (max) |
17.9 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-30 - 60 °C |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| general_information_attribute_container_name |
|---|
| attribute_product_family_name |
VIGI |
| Weight & dimensions |
|---|
| Width |
111 mm |
| Depth |
111 mm |
| Height |
81.4 mm |
| Weight |
550 g |
| Package type |
Box |
| Packaging content |
|---|
| Number of cameras |
1 |
| Mounting kit |
Yes |
| Technical details |
|---|
| Compliance certificates |
CE |
