1 2

TP-LINK

TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+

TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+

£146.40 GBP
£146.40 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

TL-SG1016PE

94 in stock

  • 16 10/100/1000Mbps RJ45 ports
  • Equipped with 8 PoE+ supported ports to transfer data and power over a single cable
  • Works with IEEE 802.3af/at compliant devices, expanding home and office networks
  • Simple network set-up on top of plug-and-play connectivity
  • Web-based user interface and management utility simplify configuration
16-Port Gigabit Easy Smart PoE Switch, 8-Port PoE+

What This Product Does

The TL-SG1016PE is an 16-Port Gigabit Desktop/Rack mountable Switch with 8 ports supporting the PoE+ standard. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable. With a total power budget of 110W, up to 30W per port, TL-SG1016PE can power more high-powered devices such as wireless Access Points (APs), IP Cameras or IP Phones. Moreover, with innovative energy-efficient technology, the TL-SG1016PE can save up to 75% of the power consumption, making it an eco-friendly solution for your business network.

Management features
Web-based management Yes
Quality of Service (QoS) support Yes
Switch layer L2
Switch type Managed
Ports & interfaces
Power connector AC-in jack
Gigabit Ethernet (copper) ports quantity 16
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 16
Network
Number of VLANs 4000
Virtual LAN features Tagged VLAN, Port-based VLAN
VLAN support Yes
Flow control support Yes
Auto MDI/MDI-X Yes
Broadcast storm control Yes
Auto-negotiation Yes
Link aggregation Yes
Port mirroring Yes
Cable types supported Cat3, Cat4, Cat5, Cat5e, Cat6
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
10G support No
Networking standards IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Data transmission
Packet buffer memory 4.1 MB
Jumbo frames 10000
Jumbo frames support Yes
Number of queues 4
Store-and-forward Yes
Forwarding rate 23.8 Mpps
Switching capacity 32 Gbit/s
MAC address table 8000 entries
Security
IGMP snooping Yes
Design
Number of fans 1 fan(s)
LED indicators Yes
Housing material Metal
Product colour Black
Form factor 1U
Stackable No
Rack mounting Yes
Performance
Compatible operating systems Windows
Maximum cable length 100 m
Technical details
Compliance certificates CE, Federal Communications Commission (FCC), RoHS
Power
Power consumption (max) 124.4 W
AC input frequency 50/60 Hz
AC input voltage 100 - 240 V
Power supply included Yes
Power source AC/PoE
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget 110 W
Power over Ethernet (PoE) power per port 30 W
Power over Ethernet plus (PoE+) ports quantity 8
Power over Ethernet (PoE) Yes
Operational conditions
Storage relative humidity (H-H) 5 - 90%
Operating relative humidity (H-H) 10 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Height 44 mm
Depth 180 mm
Width 294 mm
Packaging data
Package weight 2.28 kg
Package height 80 mm
Package depth 400 mm
Package width 250 mm
Rack mount kit Yes
Resource CD Yes
Package type Box
User guide Yes
Cables included AC
Sustainability
Sustainability compliance Yes
