• TP-Link Omada EAP225 wireless access point, 1350 Mbit/s
1 5

Omada

TP-Link Omada EAP225 wireless access point 1350 Mbit/s White Power over Ethernet (PoE)

TP-Link Omada EAP225 wireless access point 1350 Mbit/s White Power over Ethernet (PoE)

EAP225

£80.04 GBP£66.70 GBP
£0.00 GBP £80.04 GBP£66.70 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

Low stock: 5 left

Delivery & lead times

Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.

Buying 5 or more? Volume pricing

We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.

Returns & warranty

See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.

  • Simultaneous 450Mbps1 on 2.4GHz and 867Mbps1 on 5GHz totals 1317Mbps1 Wi-Fi speeds
  • EAP Controller Software lets administrators easily manage hundreds of EAPs
  • Compatibility with 802.3af and Passive PoE support makes deployment effortless and flexible
  • Captive portal provides a convenient method for guest authentication
  • Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections
  • MU-MIMO2 means access points simultaneously transfer data with multiple devices, speeding up connections
  • Beamforming concentrates signal towards where you need it most, providing a fast and stable Wi-Fi experience
  • Supports management VLAN for an enhanced network management
  • Schedules can be set so access points automatically reboot and Wi-Fi turns on/off at the times you choose
802.3af/at PoE, 12.6W, 2.4GHz: 4dBi x 3, 5GHz: 5dBi x 2, 2.4GHz and 5GHz, FCC, RoHS

Superior Wi-Fi Speeds with MU-MIMO Technology
Outfitted with the latest 802.11ac Wave 2 MU-MIMO technology, the EAP225 easily delivers dual-band Wi-Fi speeds of up to 1350 Mbps to multiple devices at the same time.

Cloud Centralized Management
- Anytime, Anywhere
Omada Hardware Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.

Facebook check-in and SMS authentication expands your social influence in secured ways
Captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.

Multiple PoE Options for Easy Installation
EAP225 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE injector, making deployment effortless and flexible.

Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.

Meet Our New Hero Product!
The OC200 Omada Hardware Controller is dedicated to providing centralized management for the whole Omada network.

Features
Transmitting power (CE) 23 dBm
Transmitting power (FCC) 24 dBm
BeamForming Yes
Quality of Service (QoS) support Yes
Airtime Fairness (ATF) Yes
Band steering Yes
Rate limiting Yes
Virtual LAN features VLAN mapping
VLAN support Yes
Wi-Fi Multimedia (WMM)/(WME) Yes
MIMO type Multi User MIMO
MIMO Yes
Cabling technology 10/100/1000Base-T(X)
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
Ethernet LAN data rates 10,100,1000 Mbit/s
Maximum data transfer rate (5 GHz) 867 Mbit/s
Maximum data transfer rate (2.4 GHz) 450 Mbit/s
Maximum data transfer rate 1350 Mbit/s
6 GHz No
5 GHz Yes
2.4 GHz Yes
Security
Access Control List (ACL) Yes
Number of SSID supported 16
Service Set Identifier (SSID) features Multiple SSIDs
MAC address filtering Yes
Security algorithms 64-bit WEP, 128-bit WEP, 152-bit WEP, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK
Management features
Syslog Yes
Web-based management Yes
Ports & interfaces
DC-in jack Yes
Ethernet LAN (RJ-45) ports 1
Power
Power consumption (typical) 10.15 W
Output current 1.5 A
Output voltage 12 V
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) type supported Passive PoE
Design
LED indicators Power, WLAN
Reset button Yes
On/off switch Yes
Cable lock slot type Kensington
Cable lock slot Yes
Product colour White
Placement Ceiling, Wall
Antenna
Antenna gain level (max) 5 dBi
Antennas quantity 5
Antenna features Integrated antenna
Antenna direction type Omni-directional
Antenna type Internal
Performance
Compatible operating systems Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux
general_information_attribute_container_name
attribute_product_family_name Omada
Mobile network
SIM card slot No
Technical details
Compliance certificates CE, Federal Communications Commission (FCC), RoHS
Weight & dimensions
Height 37.1 mm
Depth 181.5 mm
Width 205.5 mm
Packaging data
Package type Box
Package weight 910 g
Package height 65 mm
Package depth 340 mm
Package width 228 mm
Packaging content
Quick start guide Yes
Mounting kit Yes
PoE adapter included Yes
AC adapter included Yes
Operational conditions
Storage relative humidity (H-H) 5 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 10 - 90%
Sustainability
Sustainability compliance Yes
Logistics data
Harmonized System (HS) code 85176990
Quantity per pack 1 pc(s)
