TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point

TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point

EAP683 UR

£186.98 GBP£155.82 GBP
£0.00 GBP £186.98 GBP£155.82 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

Low stock: 4 left

Delivery & lead times

Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.

Buying 5 or more? Volume pricing

We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.

Returns & warranty

See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.

  • 2.4 GHz 1148 Mbit/s
  • 5 GHz 4804 Mbit/s
  • Maximum data transfer rate: 6000 Mbit/s
  • IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
  • HTTPS, SNMP, SNMPv2, SNMPv3, SSH
  • Power over Ethernet (PoE)
  • Internal
Omada AX6000 Ceiling Mount WiFi 6 EAP683 UR
Features
2.4 GHz Yes
6 GHz No
5 GHz Yes
Maximum data transfer rate 6000 Mbit/s
Maximum data transfer rate (2.4 GHz) 1148 Mbit/s
Maximum data transfer rate (5 GHz) 4804 Mbit/s
Ethernet LAN data rates 10,100,1000,2500 Mbit/s
Frequency band 2.4 - 6 GHz
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
Number of users 510 user(s)
Automatic channel scanning Yes
Automatic channel selection Yes
MIMO Yes
MIMO type Multi User MIMO
Fast roaming Yes
VLAN support Yes
Rate limiting Yes
Band steering Yes
Airtime Fairness (ATF) Yes
Quality of Service (QoS) support Yes
BeamForming Yes
Security
Security algorithms HTTPS, SNMP, SNMPv2, SNMPv3, SSH
MAC address filtering Yes
Service Set Identifier (SSID) features Multiple SSIDs
Access Control List (ACL) Yes
Management features
Syslog Yes
Firmware upgradeable Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
DC-in jack Yes
Power
Power over Ethernet (PoE) Yes
DC voltage range 12 V
Design
Placement Ceiling, Wall
Product colour White
Reset button Yes
LED indicators Yes
Antenna
Antenna type Internal
Antenna direction type Omni-directional
Antenna gain level (max) 5 dBi
general_information_attribute_container_name
attribute_product_family_name Omada
Weight & dimensions
Width 220 mm
Depth 220 mm
Height 32.5 mm
Packaging data
Package type Box
Packaging content
Mounting kit Yes
Quick start guide Yes
Operational conditions
Operating relative humidity (H-H) 10 - 90%
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 5 - 90%
Logistics data
Quantity per pack 1 pc(s)
