TP-LINK

TP-Link Omada AX3000 Wall Plate WiFi 6 Access Point

TP-Link Omada AX3000 Wall Plate WiFi 6 Access Point

£92.83 GBP
£92.83 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

EAP615-WALL

60 in stock

  • Superior WiFi 6 Speeds - Delivers dual-band speeds of up to 18 Gbps powered by the latest WiFi 6 technology
  • Complete In-Room WiFi Coverage - Guarantees strong signals and corner-to-corner WiFi coverage in each room
  • Higher Network Efficiency - OFDMA and DL/UL MU-MIMO* deliver data to multiple devices simultaneously with less lag
  • Full Gigabit Ports - Connect multiple devices with four gigabit ports and one downlink port offering PoE pass-through
  • Centralized Cloud Management - Integrates into Omada SDN for cloud access and remote management
IEEE 802.11ax/ac/n/g/b/, 2.4 / 5GHz, 574 / 1201Mbps, 802.3af/at PoE, 143 × 86 × 20 mm

The Smarter Cloud Solution for Business Networking.
AX1800 Wall Plate WiFi 6 Access Point

Futureproof Your Network with WiFi 6 Connectivity
Connect more devices at the same time with WiFi 6 speeds of up to 1800 Mbps..

Corner-to-Corner Indoor WiFi Coverage
Guests can enjoy strong private networks that paint their entire space by installing EAP615-Walls in each guest room.

Features
Transmitting power (CE) 20 dBm
Transmitting power (FCC) 21 dBm
BeamForming Yes
Quality of Service (QoS) support Yes
Airtime Fairness (ATF) Yes
Band steering Yes
Wireless isolation Yes
Rate limiting Yes
VLAN support Yes
MIMO type Multi User MIMO
MIMO Yes
Automatic channel selection Yes
Automatic channel scanning Yes
Cabling technology 10/100/1000Base-T(X)
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates 10,100,1000 Mbit/s
Maximum data transfer rate (5 GHz) 1201 Mbit/s
Maximum data transfer rate (2.4 GHz) 574 Mbit/s
Maximum data transfer rate 1774 Mbit/s
6 GHz No
5 GHz Yes
2.4 GHz Yes
Security
Access Control List (ACL) Yes
Remote Authentication Dial-In User Service (RADIUS) Yes
Number of SSID supported 16
Service Set Identifier (SSID) features Multiple SSIDs
Security algorithms WPA, WPA2, WPA3
Protocols
STelnet using SSH v2 Yes
Management features
Firmware upgradeable Yes
Syslog Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports 4
Power
Power over Ethernet (PoE) Yes
Design
Certification CE, FCC, RoHS
LED indicators Power
Reset button Yes
On/off switch Yes
Product colour White
Placement Wall
Antenna
Antenna gain level (max) 4 dBi
Antennas quantity 4
Antenna type Internal
general_information_attribute_container_name
attribute_product_family_name Omada
Weight & dimensions
Height 20 mm
Depth 86 mm
Width 143 mm
Packaging data
Package weight 330 g
Package height 210 mm
Package depth 495 mm
Package width 385 mm
Operational conditions
Storage relative humidity (H-H) 5 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 10 - 90%
Logistics data
Harmonized System (HS) code 85176990
