TP-LINK

TP-Link Load Balance Broadband Router

TP-Link Load Balance Broadband Router

Regular price £32.87 GBP
Regular price Sale price £32.87 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

SKU:TL-R470T+ V1

Low stock: 9 left

  • Up to 4 WAN ports equipped with advanced load balance to guarantee maximum bandwidth and backup capabilities
  • Portal Authentication enables efficient access management
  • Marshals bandwidth resource to specific clients based on their unique application environments
  • Smaller case for cost-effective solution in the small office or Internet cafes network
10/100BASE, LAN/WAN, 16MB Flash, 128MB DRAM, 158 × 101 × 25mm

What This Product Does
The TL-R470T+ load balance broadband router is a wise choice for small business. It brings you high return on investment with low overhead. Featuring three changeable WAN/LAN ports, TL-R470T+ supports up to 4 WAN ports, which can satisfy various Internet access requirements through one device. TL-R470T+ integrates multiple load balancing strategies, advanced QoS and strong firewall to provide you with consistent network uptime and reliable Ethernet connectivity. Moreover, it is easy to manage the TL-R470T+ via a web-based utility, which makes building and managing your network more convenient.

Three Changeable WAN/LAN Ports
The TL-R470T+ features three changeable ports that can be set to either LAN or WAN, allowing the router to support up to four WAN ports to satisfy various Internet access requirements through one device. The router also has an integrated smart load balancing function which automatically selects the most efficient line according to load and bandwidth requirements, providing users with consistent network uptime and reliable Ethernet connectivity.

Abundant Security Features
For defense against external threats, TL-R470T+ can automatically detect and block Denial of service (DoS) attacks such as TCP/UDP/ICMP Flooding, Ping of Death and other related threats. Moreover, this router provides IP/MAC/URL/WEB ­filtering functions, which forcefully prevent attacks from intruders and viruses. For applications such as FTP, H.323, SIP, IPsec and PPTP which are not well compatible with NAT, TL-R470T+ offers administrators one-click enable of ALG choices corresponding to the above five applications.

Efficient Access Management
By setting a PPPoE Server to allocate PPPoE accounts to private network users, the router only allows users with legal accounts that have passed authentication to access the Internet. Cooperating with IP-based Bandwidth Control, it is capable of confining bandwidth usage of certain PPPoE accounts. Moreover, the E-Bulletin function is able to release a bulletin in the form of webpage to certain user groups periodically, which notifies the users about the expiration date of the PPPoE account. With the above features, the router will prioritize different users in surfer jurisdictions for more efficient management.

Safety Minded Enterprise Investments
Professional lightning protection technology is designed to prevent electrical surges from penetrating the interior of the device, to be discharged harmlessly into the Earth. This router is designed to prevent lightning damage of up to 4KV in the well-grounded connection conditions. This feature ensures that networking infrastructure investments remain as safe as possible from one of Mother Nature’s more violent elements.

WAN connection
3G/4G USB modem compatibility No
SIM card slot No
DSL WAN No
Ethernet WAN Yes
Network
Concurrent connections 10000
Policy-based routing Yes
Traffic control Yes
Static route Yes
VLAN support Yes
Full duplex No
Ethernet LAN data rates 10,100 Mbit/s
Cabling technology 10/100Base-T(X)
Ethernet interface type Fast Ethernet
Networking standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Management features
Reset button Yes
Universal Plug and Play (UPnP) Yes
Quality of Service (QoS) support Yes
Web-based management Yes
Ports & interfaces
DC-in jack Yes
Fast Ethernet (copper) ports quantity 5
Ethernet LAN (RJ-45) ports 5
Protocols
Supported network protocols TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS
DMZ support Yes
DHCP client Yes
DHCP server Yes
Security
VPN support PPTP/L2TP/IP Sec
System event log Yes
Network address translation (NAT) Yes
ARP attack prevention Yes
DoS attack prevention Yes
IP address filtering Yes
URL filtering Yes
MAC address filtering Yes
Firewall Yes
Security algorithms HTTPS
Features
Certification CE, FCC, RoHS
Linux operating systems supported Yes
Mac operating systems supported macOS
Windows operating systems supported Windows 7, Windows 8, Windows Vista, Windows XP
Internal memory type DRAM
Internal memory 64 MB
Flash memory 4 MB
Design
LED indicators LAN, Power, System, WAN, WLAN
Rack mounting No
Product colour Black
Power
Power over Ethernet (PoE) No
AC input frequency 50 - 60 Hz
AC input voltage 100 - 240 V
Power source type AC
Power consumption (typical) 1.56 W
Operational conditions
Storage relative humidity (H-H) 5 - 90%
Operating relative humidity (H-H) 10 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Height 26 mm
Depth 126 mm
Width 209 mm
Packaging data
Package weight 630 g
Package height 60 mm
Package depth 254 mm
Package width 190 mm
Cables included AC, LAN (RJ-45)
Logistics data
Harmonized System (HS) code 85176990
