TP-Link AV1000 Gigabit Passthrough Powerline Starter Kit

HomePlug AV2, 1000 Mbps, Gigabit Ethernet, OFDM, 128-bit AES, 2.7 W

---

Gigabit Network Goes Further
with AV1000 Powerline
HomePlug AV2
AV1000 Gigabit Passthrough Powerline Starter Kit
TL-PA7017P KIT

1000 Mbps!
Perfect for Bandwidth-Hungry Activities
Coming with advanced HomePlug AV2 technology, TL-PA7017P KIT provides users with high-speed data transfer rates of up to 1000 Mbps—ideal for bandwidth-intensive applications such as multiple HD/3D/4K video streaming, online gaming, and large file transfers.

Gigabit Port for
Ultra-Fast Data Transfer
With one Gigabit Ethernet port, TL-PA7017P KIT allows users to connect a bandwidth-intensive device to the internet at high speeds, ensuring smooth streaming for Ultra HD videos. This makes the TL-PA7017P KIT the perfect home entertainment companion.

Plug and Play, No Configuration Required
Connect a powerline adapter to the router. Plug another powerline adapter into a wall socket in another room. Connect it to your internet enabled device via Ethernet—and you’re done!

Extra Power Outlet for Additional Devices
Finding it hard to plug in your devices? The TL-PA7017P KIT has an integrated AC pass-through power socket. Your powerline adapter can now be used like a traditional electrical outlet. Plug your smart TV or game consoles into the adapter. No socket left to waste.

Up to 85% Power Saved
The future’s looking green for powerline adapters. TL-PA7017P KIT’s practical design and sophisticated Power-Saving Mode, which automatically switches from its regular "Working" mode to "Power-Saving" mode, reduces its energy consumption by up to 85%

---

Performance
Plug and Play	Yes
Encryption button	Yes
Maximum operating distance	300 m
Security algorithms	128-bit AES
Modulation	OFDM
PowerLine standard	HomePlug AV2
Built-in power socket	Yes
Power plug	Type E / F
Networking standards	IEEE 1901, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Wi-Fi	No
Ethernet LAN (RJ-45) ports	1
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
Maximum data transfer rate	1000 Mbit/s

Power
Power consumption (standby)	0.5 W
Power consumption (typical)	2.3 W

Design
Certification	CE
Product colour	White
LED indicators	LAN, PLC, Power

System requirements
Mac operating systems supported	Yes
Linux operating systems supported	Yes
Mac compatibility	Yes
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP

Operational conditions
Storage relative humidity (H-H)	5 - 90%
Operating relative humidity (H-H)	10 - 90%
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight & dimensions
Package weight	580 g
Package height	100 mm
Package depth	136 mm
Package width	190 mm
Height	95 mm
Depth	42 mm
Width	58 mm

Technical details
Compliance certificates	RoHS

Packaging content
Cables included	LAN (RJ-45)
Quick installation guide	Yes
Quantity per pack	2 pc(s)

Logistics data
Harmonized System (HS) code	85171800
