1 4

TP-LINK

TP-Link 5-Port 10/100Mbps Desktop PoE Switch with 4-Port

TP-Link 5-Port 10/100Mbps Desktop PoE Switch with 4-Port

£34.79 GBP
£34.79 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

TL-SF1005P V1

69 in stock

  • 5 10/100Mbps RJ45 ports
  • With four PoE ports, transfers data and power on one single cable
  • Working with IEEE 802.3af compliant PDs, expands home and office network
  • Supports PoE Power up to 15.4W for each PoE port
  • Supports PoE Power up to 58W for all PoE ports
  • Requires no configuration and installation
5x 10/100Mbps RJ-45, PoE, 1 Gbps, 99.8x98x25 mm

PoE Switches for Your Ultra Convenience
5-Port 10/100Mbps Desktop Switch with 4-Port PoE

Power over Ethernet
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).

Intelligent Power Management
When total power consumption excels 58W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.

Sturdy Metal Casing
Sturdy, compact metal casing and shielded RJ45 ports, with desktop/wall-mounting design, to meet your needs in any environment. Besides, fanless design ensures quiet operation.

Management features
Switch type Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity 5
Network
MAC address auto-aging supported Yes
Flow control support Yes
Auto MDI/MDI-X Yes
MAC address auto-learning supported Yes
Auto-negotiation Yes
Half duplex Yes
Full duplex Yes
Cable types supported Cat3, Cat4, Cat5, Cat5e, Cat6
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 100BASE-T
10G support No
Networking standards IEEE 802.3af, IEEE 802.3x
Data transmission
Jumbo frames 2000
Jumbo frames support Yes
Store-and-forward Yes
Forwarding rate 0.744 Mpps
Switching capacity 1 Gbit/s
MAC address table 2000 entries
Design
LED indicators Yes
Product colour Black
Stackable No
Rack mounting No
Performance
Fanless Yes
Maximum cable length 100 m
Technical details
Compliance certificates CE, Federal Communications Commission (FCC), RoHS
Power
Power consumption (max) 74 W
Input current 1.31 A
DC input voltage 53.5 V
AC input frequency 50 Hz
AC input voltage 220 V
Power supply included No
Power source DC/PoE
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget 67 W
Power over Ethernet plus (PoE+) ports quantity 4
Power over Ethernet (PoE) Yes
Operational conditions
Heat dissipation 252.34 BTU/h
Storage relative humidity (H-H) 5 - 90%
Operating relative humidity (H-H) 10 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Height 25 mm
Depth 98 mm
Width 99.8 mm
Packaging data
Package weight 760 g
Package height 121 mm
Package depth 196 mm
Package width 131 mm
Package type Box
User guide Yes
AC adapter included Yes
Sustainability
Sustainability compliance Yes
Sustainability certificates CE, Federal Communications Commission (FCC), RoHS
Logistics data
Harmonized System (HS) code 85176990
