SUNIX Group SER6437AL interface cards/adapter Internal RS-232

SUNIX Group SER6437AL interface cards/adapter Internal RS-232

SER6437AL

£36.10 GBP£30.08 GBP
£0.00 GBP £36.10 GBP£30.08 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

32 in stock

Delivery & lead times

Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.

Buying 5 or more? Volume pricing

We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.

Returns & warranty

See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.

  • Internal
  • Host interface: PCIe
  • Output interface: RS-232
SER6437AL - 2-port RS-232 Low Profile PCI Express Board

SUNIX SER6437AL, PCI Express serial communication board meets the PCI Express Base Specification Revision 2.0, allows users to add or expand two RS-232 COM ports on PC-based system to use serial devices further. It is compatible with PCI Express x1, x2, x4, x8 and x16 lane Bus allowing it to be installed in any PC-based system with low profile bracket structure. The majorities of today’s motherboard is not equipped with serial ports or only have one serial port. With SUNIX PCI Express serial board, users can add one serial port to their system, allowing them to use serial devices further. SUNIX SER6437AL card has 128-bytes onboard FIFO buffer and compatible with 16C950 UART specifications. It is designed with SUNIX UART controller, SUN2212 and as well built with many of SUNIX advanced features and technologies, making it the best solution for commercial and industrial automation applications.

Ports & interfaces
SATA revision 2.0
Output interface RS-232
Host interface PCIe
Design
Certification CE, FCC, VCCI, BSMI
Internal Yes
Features
Plug and Play Yes
Flow Control type No, RTS/CTS, XON/XOFF
Flow control support Yes
Parity bit Even, Mark, No, Odd, Space
Stop bits 1, 1.5, 2
FIFO (First In, First Out) 128 B
Baud rate 115.2 Kbit/s
Operational conditions
Operating relative humidity (H-H) 5 - 95%
Storage temperature (T-T) -20 - 85 °C
Operating temperature (T-T) 0 - 60 °C
System requirements
Linux operating systems supported Yes
Windows operating systems supported Yes
Weight & dimensions
Height 68 mm
Width 65 mm
Packaging data
Package type Box
Quick installation guide Yes
Mounting brackets included Yes
Quantity 1
Logistics data
Harmonized System (HS) code 84733020
