StarTech.com

StarTech.com Gigabit Ethernet Fiber Media Converter Card Module with Open SFP Slot

StarTech.com Gigabit Ethernet Fiber Media Converter Card Module with Open SFP Slot

Regular price £94.45 GBP
Regular price Sale price £94.45 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

SKU:ET91000SFP2C

Low stock: 3 left

  • Wired
  • 1250 Mbit/s
  • Ethernet LAN (RJ-45) ports: 1
  • Fiber ports quantity: 1 SFP
  • Internal
  • Black, Green
StarTech.com Gigabit Ethernet Fiber Media Converter Card Module w/ Open SFP Slot - Fiber to Ethernet Converter - Ethernet Media Converter

Convert and extend a Gigabit Ethernet connection over fiber, using the Gigabit SFP of your choice

The ET91000SFP2C Open SFP Fiber Media Converter card module converts and extends a Gigabit Ethernet connection over fiber, using the Gigabit SFP of your choice.

A versatile solution for connecting an Ethernet (1000Base-T) network to remote network segments over a fiber backbone, the media converter features an open SFP slot that lets you choose the MSA-Compliant Gigabit SFP that best suits your fiber connection mode (single / multi-mode) and distance requirements (see our full line of for compatible solutions).

Designed for applications where multiple chassis-powered media converters are required, this Gigabit media converter ships as a card module that can easily be installed into the 20 Slot, ETCHS2U" text="2U Rackmount Chassis (ETCHS2U). For standalone operation this Gigabit media converter can also be purchased as a standard ET91000SFP2" text="Open SFP Media Converter (ET91000SFP2).

The fiber to Ethernet converter offers simple plug-and-play installation, while support for full-duplex operation and Jumbo Frame support provides efficient network operation.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

- Install the SFP of your choice with the open SFP slot
- Easily set up a full rack mount chassis of media converters with the card module design
- Ensure maximum up-time with link-loss forwarding and remote status monitoring

Network
Duplex system Full, Half
Auto MDI/MDI-X Yes
Ethernet LAN data rates 1000 Mbit/s
Ethernet interface type Gigabit Ethernet
Networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z
Converter output interface 1000Base-LX, 1000Base-SX
Converter input interface 1000Base-T
Maximum data transfer rate 1250 Mbit/s
Ports & interfaces
Fiber optic connector SFP
Fiber ports quantity 1
Ethernet LAN (RJ-45) ports 1
Connectivity technology Wired
Performance
Mean time between failures (MTBF) 65000 h
Design
Certification FCC
LED indicators Yes
Product colour Black, Green
Internal Yes
Power
External power adapter No
Power over Ethernet (PoE) No
Power consumption (typical) 8 W
Input current 1 A
Input voltage 12 V
Weight & dimensions
Weight 100 g
Height 20 mm
Depth 140 mm
Width 75 mm
Operational conditions
Operating relative humidity (H-H) 10 - 90%
Storage temperature (T-T) -10 - 70 °C
Operating temperature (T-T) 0 - 60 °C
Packaging data
Package weight 184 g
Package height 27 mm
Package depth 185 mm
Package width 130 mm
Packaging content
Manual Yes
Technical details
Compliance certificates RoHS
Logistics data
Harmonized System (HS) code 85176990
