StarTech.com 80x25mm Computer Case Fan with PWM – Pulse Width Modulation Connector

StarTech.com 80x25mm Computer Case Fan with PWM – Pulse Width Modulation Connector

£8.04 GBP
£8.04 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

FAN8025PWM

20 in stock

  • 4-pin Pulse Width Modulation (PWM) motherboard connector
  • Ever Lubricate Bearing design
  • Includes a PWM Y-split cable
StarTech 80x25mm Computer Case Fan with PWM - Pulse Width Modulation Connector - computer cooling Fan - 80mm Fan - pwm Fan (FAN8025PWM)

Add a Variable Speed, PWM-Controlled Cooling Fan to a Computer Case

The FAN8025PWM 80mm PWM Case Fan adds an efficient air cooling solution to computer cases or other enclosures, to keep components running optimally.

With Pulse Width Modulation (PWM) technology, the fan speed can be dynamically controlled by the motherboard, so the fan runs at a speed that suits the operating conditions - lowering power consumption and fan noise when the system is idle, and delivering maximum cooling under full load conditions.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Performance
Suitable location Computer case
Type Fan
Fan diameter 8 cm
Noise level (high speed) 28 dB
Mean time between failures (MTBF) 40000 h
Operating temperature (T-T) -10 - 70 °C
Design
Product colour Black
Material Plastic
Power
Voltage 12 V
Rated current 0.16 A
Weight & dimensions
Weight 86 g
Package width 396 mm
Package depth 143 mm
Package height 34 mm
Package weight 111 g
Other features
Operating relative humidity (H-H) 0 - 65%
Storage relative humidity (H-H) -20 - 70%
Fan performance 25.02 cfm
Connector(s) 1 - Molex Fan (4 pin; PWM)
Rotational speed 2500 RPM
Dimensions (WxDxH) 80 x 80 x 25 mm
Logistics data
Harmonized System (HS) code 84733080
Master (outer) case width 366 mm
Master (outer) case length 588 mm
Master (outer) case height 218 mm
Products per master (outer) case 100 pc(s)
