StarTech.com

StarTech.com 3ft (1m) DisplayPort to VGA Cable - Active DisplayPort to VGA Adapter Cable - 1080p Video - DP to VGA Monitor Cable - DP 1.2 to VGA Converter - Latching DP Connector

StarTech.com 3ft (1m) DisplayPort to VGA Cable - Active DisplayPort to VGA Adapter Cable - 1080p Video - DP to VGA Monitor Cable - DP 1.2 to VGA Converter - Latching DP Connector

Regular price £25.13 GBP
Regular price Sale price £25.13 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

SKU:DP2VGAMM3B

40 in stock

  • DISPLAYPORT TO VGA CABLE: 3ft (1m) DisplayPort 1.2 (HBR2) adapter cable lets you connect a single VGA display supporting 2048x1280, 1920x1200 & 1920x1080 (1080p) at 60Hz; EDID & DDC pass-through ensure compatibility between source & display
  • COMPATIBILITY: Active digital to analog converter supports DP or DP++ source w/ standard DP connector incl workstations, desktops (AMD/Nvidia), laptops, small form factor computers & docking stations
  • INTEGRATED DISPLAY CABLE: Adapter cable has a slim & flexible design w/ adapter chip built into VGA connector reducing clutter & providing a tidy install at your desk workstation in the office or home office
  • LATCHING DISPLAYPORT & SCREW LOCKING VGA: Latching DP connector ensures a solid host connection, and chip built into VGA connector minimizes signal loss / Supports VGA screw locking cable to prevent cable from coming loose or accidental disconnection
  • EASY TO USE: With no software or drivers required, the DP to VGA video converter cable/cord works with any OS including macOS, Windows & Ubuntu / DP Source to VGA Monitor/Display/Projector/ DisplayPort Male to VGA Male Cable
StarTech.com 3ft (1m) DisplayPort to VGA Cable - Active DisplayPort to VGA Adapter Cable - 1080p Video - DP to VGA Monitor Cable - DP 1.2 to VGA Converter - Latching DP Connector (DP2VGAMM3B)

Connect a DisplayPort-equipped PC to a nearby VGA monitor/Projector, with a short 3 foot cable

The DP2VGAMM3B active DisplayPort to VGA converter cable lets you connect your DisplayPort-equipped desktop or laptop directly to a nearby VGA monitor or projector, saving the expense of additional adapters while eliminating the clutter of excess cable.

Plus, because the converter cable supports video resolutions up to 1920x1200 you can convert a DisplayPort video source to VGA without sacrificing video quality.

The DP2VGAMM3B is backed by a 3-year StarTech.com warranty and free lifetime technical support.

The StarTech.com Advantage

Features
Converter type Active video converter
Plug and Play Yes
Chipset Analogix - 9832
Product colour Black
HBR2 support Yes
Maximum refresh rate 60 Hz
Supported graphics resolutions 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1280
Maximum resolution 2048 x 1280 pixels
DisplayPort version 1.2
Connector 2 form factor Straight
Connector 1 form factor Straight
Connector 2 gender Male
Connector 1 gender Male
Connector 2 VGA (D-Sub)
Connector 1 DisplayPort
Cable length 0.91 m
Operational conditions
Operating relative humidity (H-H) 40 - 85%
Storage temperature (T-T) -10 - 70 °C
Operating temperature (T-T) 0 - 60 °C
Weight & dimensions
Height 15 mm
Depth 915 mm
Width 40 mm
Weight 79 g
Packaging data
Package weight 90 g
Package height 20 mm
Package depth 240 mm
Package width 160 mm
Quantity per pack 1 pc(s)
Technical details
Compliance certificates CE, RoHS
Logistics data
Products per master (outer) case 220 pc(s)
Master (outer) case height 435 mm
Master (outer) case length 415 mm
Master (outer) case width 420 mm
Harmonized System (HS) code 84733080
