StarTech.com 10ft (3m) DisplayPort 1.2 Cable - 4K x 2K Ultra HD VESA Certified DisplayPort Cable - DP to DP Cable for Monitor - DP Video/Display Cord - Latching DP Connectors
StarTech.com 10ft (3m) DisplayPort 1.2 Cable - 4K x 2K Ultra HD VESA Certified DisplayPort Cable - DP to DP Cable for Monitor - DP Video/Display Cord - Latching DP Connectors
SKU:DISPLPORT10L
35 in stock
- HIGH PERFORMANCE CABLE: This 10ft (3m) VESA Certified DisplayPort v1.2 cable supports 4K x 2K (3840x2400p 60Hz), 21.6 Gbps bandwidth, HBR2, 8Ch Audio, Multi-Stream Transport (MST), GTC for precise audio channel timing & 3D Stereo (2560x1600p 120Hz)
- RELIABLE DESIGN: Durable ABS connectors with flexible PVC strain relief & jacket prevents fraying/damage due to bending or rough usage; Metal connector sub-structure provides EMI shielding; Latching DP connectors prevent accidental disconnection
- QUALITY CONSTRUCTION: 28AWG wire with gold-plated connectors for improved signal integrity and reliability; Superior EMI shielding with Al-Mylar foil and copper braid provides higher quality video and audio; Backwards compatible with DP 1.1
- APPLICATIONS: Ideal for home/offices/boardrooms/conference rooms/classrooms; works with your professional workstations with FirePro™ S9000/7000, W8100/7100/5100 or R5000 graphic cards; Use with 1080p/UHD/4K monitors, projector or large display
- SPECS: 10 ft (3 m) / Black / DisplayPort v1.2 / DP Latching Male to Male / 28 AWG / PVC cable jacket, ABS connector shell / Shield: Al-Mylar foil with Braid / Protocols: HBR 2, MST, GTC / Lifetime Warranty
Create high-resolution 4K x 2K connections with HBR2 support between your DisplayPort equipped devices
This DisplayPort cable provides a secure connection between your DisplayPort equipped devices and is capable of providing higher performance than either HDMI® or dual-link DVI.
The DP cable supports high resolutions of up to 4K x 2K (4096 x 2160, 60Hz) with a maximum HBR2 bandwidth of 21.6Gbps, as well as optional audio support. The cable also supports Multi-Stream Transport (MST) for daisy chaining multiple monitors.
The 10-foot cable is DisplayPort (VESA) certified to support DP 1.2 specifications and ensure a high-quality, reliable connection for all of your DisplayPort devices.
The DISPLPORT10L is backed by a StarTech.com lifetime warranty for guaranteed reliability and ensures that digitally protected content is displayed properly, with both HDCP and DPCP capability.
The StarTech.com Advantage
Features | |
---|---|
Number of conductors | 19 |
Multi-Stream Transport (MST) | Yes |
Plug and Play | Yes |
Bandwidth | 21600 MB/s |
AWG wire size | 28 |
Jacket material | Polyvinyl chloride (PVC) |
Cable shielding | Aluminum mylar foil |
Cable rating | CMG (CM) |
Product colour | Black |
Latching connectors | Yes |
DisplayPort Content Protection (DPCP) | Yes |
HDCP | Yes |
Maximum refresh rate | 120 Hz |
Supported graphics resolutions | 3840 x 2400, 2560 x 1600 (WQXGA) |
Maximum resolution | 3840 x 2400 pixels |
DisplayPort version | 1.2 |
Connector contacts plating | Nickel |
Connector 2 form factor | Straight |
Connector 1 form factor | Straight |
Connector 2 gender | Male |
Connector 1 gender | Male |
Connector 2 | DisplayPort |
Connector 1 | DisplayPort |
Cable length | 3 m |
Packaging data | |
---|---|
Package weight | 215 g |
Package height | 34 mm |
Package depth | 220 mm |
Package width | 200 mm |
Quantity per pack | 1 pc(s) |
Weight | 210 g |
Cable diameter | 7.3 mm |
Technical details | |
---|---|
Compliance certificates | RoHS |
Logistics data | |
---|---|
Products per master (outer) case | 50 pc(s) |
Master (outer) case height | 280 mm |
Master (outer) case length | 500 mm |
Master (outer) case width | 330 mm |
Harmonized System (HS) code | 84733080 |
