PLANET PWR-75-48 power supply unit 75 W Blue, Grey

PLANET PWR-75-48 power supply unit 75 W Blue, Grey

PWR-75-48

£38.88 GBP£32.40 GBP
£0.00 GBP £38.88 GBP£32.40 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

14 in stock

Delivery & lead times

Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.

Buying 5 or more? Volume pricing

We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.

Returns & warranty

See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.

  • Universal AC input / full range
  • Protection features: short circuit, overload, over voltage and over temperature
  • Cooling by free air convection
  • DIN rail TS-35/7.5 or 15 installation
  • UL 508 (industrial control equipment) approved
  • EN61000-6-2 (EN50082-2) industrial immunity level
  • 100% full load burn-in test
DC Single Output Industrial DIN Rail Power Supply Units

Compact Size with more Practicability and Convenience
PLANET has released a series of DC single output industrial DIN rail power supply units to make sure that industrial Ethernet devices, specially designed for the harsh working environment, get DC voltage power easily.
PLANET DC single output industrial DIN rail power supply units accept universal 100-240V AC input voltage and provide 48V DC power output with various watt values. Its power supply units are designed in compact size and can be installed on DIN rail TS-35 / 7.5 or 15. It is an ideal and convenient DC power feeding solution for Industrial equipment under heavy Industrial environments.

Stable Performance under Difficult Environments
PLANET DC single output industrial DIN rail power supply units come with such protection features as short circuit, overload, over voltage and over temperature for the stable operation of industrial Ethernet equipment. It uses the free air convection cooling system to prevent operating temperature from rising. Being able to operate under the temperature range from -20 to 70 degrees C (maximum), the DC single output industrial DIN rail power supply units can be placed in almost any difficult environments.

Power
Power protection features Over voltage, Overheating, Overload, Short circuit
Input current 1.45 A
AC input frequency 50 - 60 Hz
AC input voltage 100 - 240 V
Total power 75 W
Performance
Safety Ul508, TUV EN60950-1
Design
Cooling type Passive
Product colour Blue, Grey
Operational conditions
Storage relative humidity (H-H) 10 - 95%
Operating relative humidity (H-H) 20 - 95%
Storage temperature (T-T) -40 - 85 °C
Operating temperature (T-T) -20 - 70 °C
Weight & dimensions
Weight 510 g
Height 102 mm
Depth 125 mm
Width 32 mm
Logistics data
Harmonized System (HS) code 84733020
