PLANET MTB-TSR2 network transceiver module Fiber optic 10000 Mbit/s SFP+ 1310 nm

• Complies with the IEEE 802.3ae 10 Gigabit Ethernet Standard
• Compact RJ45 connector assembly
• SFP+ multi-source agreement compliant
• SFF-8472 diagnostic monitoring interface for optical transceivers
• For established fiber link distance up to 300m over 50/125μm multi-mode fiber cable
• For established fiber link distance up to 60km over 9/125μm single-mode fiber cable
• Cost-effective at up to 30m distance on UTP cables

The PLANET MTB family of 10G SFP+ fiber optic module that is designed to work with PLANET products with 10G SFP+ interface provides a high-performance 10G Ethernet network for enterprises, telecoms and ISPs. The MTB family is also well applicable for data center cloud computing. The deployment distance can be extended from 300 meters (multi-mode, LC), to up to 60 kilometers (single-mode, LC).

To meet the increasing demand of the Industrial Ethernet fiber solution, PLANET has released the MTB-T series 10GBASE-SR/LR/BX transceivers that can operate reliably in an electrically harsh, climatically demanding, and -40 to 75 degrees C operating temperature environment. The MTB-T series 10GBASE-SR/LR/BX transceivers are definitely easier and faster to connect than the 1000BASE-SX/LX/BX counterpart.

The 10GBASE-T SFP+ Copper Transceiver is specifically designed for high-speed communication links that require 10 gigabit Ethernet over Cat 6a/7 cable. It is the first SFP+ transceiver that offers 10Gb/s communication over fiber optic media.

Interoperability with legacy Ethernet equipment via auto-negotiation is of particular significance as it enables data center to expand without added expenses. The added benefit is that it provides backward compatibility with legacy networks by adopting standard-based technology of the familiar RJ45 connector.
