• NETGEAR XSM4328FV network switch, Managed, black
1 5

Netgear

NETGEAR XSM4328FV Managed L3 1U Black

NETGEAR XSM4328FV Managed L3 1U Black

XSM4328FV-100NES

£3,743.18 GBP£3,119.32 GBP
£0.00 GBP £3,743.18 GBP£3,119.32 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

12 in stock

Delivery & lead times

Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.

Buying 5 or more? Volume pricing

We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.

Returns & warranty

See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.

  • 24 10GBASE-X SFP+ ports with 4 25GBASE-X SFP28 uplinks
  • 240W internal power supply
  • 1 slot for modular power supply (1+1 redundancy)
  • Any APS350Wv1, APS600Wv2, APS920Wv1, or APS2000Wv1 can be used
  • Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover
  • Layer 3 feature set includes static, policy-based, and dynamic routing
  • NETGEAR IGMP Plus™, AV User Interface, and Engage Controller speed up AV installations
24 x 10GBASE-X SFP+, 4 x 25GBASE-X SFP28, 240W, L3, 440 x 400 x 43.2 mm, 6.25Kg

POWER AND THROUGHPUT
Edge to core stackable platform, from 1 Gigabit to 100 Gigabit, all within 15.75in (40cm) of depth.

Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.

Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.

Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.

FAST, EASY CONFIGURATION FOR AV PROS
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.

FOCUS ON THE EVENT NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise.

DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX
With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.

Management features
Switch type Managed
Switch layer L3
Quality of Service (QoS) support Yes
Web-based management Yes
ARP inspection Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type No
SFP+ module slots quantity 24
Console port RJ-45
SFP28 ports quantity 4
USB 2.0 ports quantity 2
Power connector AC-in jack
Network
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ak, IEEE 802.3bz, IEEE 802.3u
10G support Yes
Policy-based routing Yes
Full duplex Yes
6to4 tunnel Yes
IPv6 routes 256
IPv4 routes 512
Rate limiting Yes
Spanning tree protocol Yes
Link aggregation Yes
Broadcast storm control Yes
Flow control support Yes
VLAN support Yes
Virtual LAN features MAC address-based VLAN, Private VLAN, Voice VLAN
Number of VLANs 4093
Data transmission
MAC address table 16000 entries
Switching capacity 680 Gbit/s
Throughput 505.92 Mpps
Store-and-forward Yes
Latency (1 Gbps) 1.06 µs
Latency (10 Gbps) 0.63 µs
Static route Yes
Jumbo frames support Yes
Jumbo frames 12000
Packet buffer memory 32 MB
Security
DHCP features DHCP Option 150, DHCP Option 66, DHCP Option 67, DHCP relay, DHCP server, DHCP snooping
Access Control List (ACL) Yes
Access Control List (ACL) egress 1023
Access Control List (ACL) ingress 511
IGMP proxy Yes
IGMP snooping Yes
Root protection Yes
Static port security Yes
DoS attack prevention Yes
Password protection Yes
Loop protection Yes
BPDU filtering/protection Yes
Authentication Guest VLAN, MAC-based authentication
Queue scheduling algorithms Strict Priority Queue (SPQ), Weighted random early detection (WRED)
Authentication type RADIUS, TACACS+
MAC address filtering Yes
Multicast features
Multicast support Yes
Multicast Listener Discovery (MLD) snooping Y
Protocols
Management protocols SNMP V1, V2, V3
Routing protocols OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2
GARP VLAN Registration Protocol (GVRP) Yes
Design
Rack mounting Yes
Stackable Yes
Form factor 1U
Product colour Black
LED indicators Yes
Airflow direction Front-to-back airflow
Performance
Built-in processor Yes
Processor model ARM Cortex-A57
Processor frequency 1800 MHz
Memory type DDR4-SDRAM
Internal memory 2048 MB
Flash memory 512 MB
sFlow Yes
Noise level 61.8 dB
Mean time between failures (MTBF) 778741 h
Technical details
Compliance certificates BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
Power
Power source AC
Power supply included Yes
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Input current 6.3 A
Power consumption (typical) 119.3 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -20 - 70 °C
Operating relative humidity (H-H) 0 - 90%
Storage relative humidity (H-H) 0 - 95%
Operating altitude 0 - 3000 m
Non-operating altitude 0 - 3000 m
Heat dissipation 374.6 BTU/h
Weight & dimensions
Width 440 mm
Depth 400 mm
Height 43.2 mm
Weight 6.25 kg
Sustainability
Sustainability compliance Yes
Packaging data
Cables included AC, USB Type-C
Included power plug types EU, NA, UK
Rack mount kit Yes
User guide Yes
Other features
Power supply 240 W
