Microconnect

Microconnect MC-USB3.0-ST610 interface cards/adapter Internal USB 3.2 Gen 1 (3.1 Gen 1)

Microconnect MC-USB3.0-ST610 interface cards/adapter Internal USB 3.2 Gen 1 (3.1 Gen 1)

£19.00 GBP
£19.00 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

MC-USB3.0-ST610

124 in stock

  • Compliant with PCI Express base specification 2.0 backward with PCI Express 1.0
  • Compliant to Universal Serial Bus 3.0 Specification Revision 1.0
  • Compliant to Universal Serial Bus 2.0 Specifications
  • Compliant to eXtensible Host Controller Interface Specification Revision 1.0
  • Support 4 Ports USB3.0 Type AF
  • Support Legacy USB Function, Four Down-stream ports Support Super-Speed (5Gbps)High-Speed(480Mbps),Full-Speed(12Mbps) and Low-Speed (1.5Mbps)
  • USB Attached SCSI Protocol(UASP)mode
  • Max. 5V/900mA power output to each USB 3.0 Port
  • 15pin SATA Power connector for extra power
  • Fully plug ,play and hot plug compatible
PCIe x1 VL805+VL812 USB3.0 (5+2)-Port Card

This product is a single-chip USB 3.0 Host controller that allows a PCI Express platform to connect with USB devices at Super-Speed (5Gbps), High-Speed (480Mbps), Full-Speed (12Mbps), and Low-Speed (1.5Mbps). It supports easy connection of mass storage, printers, scanners, hubs, cameras, and other USB devices.
Linux, Win7/Win8/Win8.1/Win10 32bit or 64 bit

Ports & interfaces
Host interface PCIe
Output interface USB 3.2 Gen 1 (3.1 Gen 1)
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 7
Internal USB 3.2 Gen 1 (3.1 Gen 1) ports quantity 1
Design
Internal Yes
Features
Chipset Via VL805 + VL812
Bandwidth 5 Gbit/s
Operational conditions
Operating temperature (T-T) 5 - 35 °C
System requirements
Windows operating systems supported Yes
Weight & dimensions
Width 174 mm
Depth 130 mm
Height 34 mm
Weight 90 g
Packaging data
Quantity per pack 1 pc(s)
Drivers included Yes
Package width 174 mm
Package depth 130 mm
Package height 34 mm
Package weight 90 g
