Microconnect MC-HDMISPLITTER0108-4K video splitter HDMI 8x HDMI

Microconnect MC-HDMISPLITTER0108-4K video splitter HDMI 8x HDMI

MC-HDMISPLITTER0108-4K

£77.32 GBP£64.43 GBP
£0.00 GBP £77.32 GBP£64.43 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

30 in stock

Delivery & lead times

Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.

Buying 5 or more? Volume pricing

We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.

Returns & warranty

See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.

  • Support three different EDID modes auto/copy/downscaler
  • Support full 3D video format
  • Support high resolution up to 4K@60Hz YUV 4:4:4
  • Support HDCP 2.2 and HDCP 1.4
  • Support High Dynamic Range (HDR) video
  • Support 600MHz/6Gbps per channel (18Gbps all channels) bandwidth
  • Support 12bit per channel (36bit all channels) deep color
  • Support uncompressed audio such as LPCM
  • Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master AudioTM and Dolby TrueHD)
HDMI 4K Splitter 1x 8 Support 4k@60Hz

The HDMITM 4K Splitter 1x8 allows you to connect an HDMI-enabled audio/video source device to eight HDMITM displays or projectors simultaneously. It supports Ultra HD (4K@60Hz), delivering stunning picture quality with four times the resolution of HD 1080p@60Hz. The splitter is also backward compatible with previous HDMITM revisions, accommodating devices with 1080p and 720p HDMITM video resolutions. Even if you don't need 4K video today, the HDMITM 4K Splitter 1x8 ensures you are prepared for future display technology advancements. It features three EDID modes—auto, copy, and downscaler—to meet the requirements of different display situations.

Ports & interfaces
Video ports quantity 9
Video port type HDMI
Video out 8x HDMI
HDMI version 2.0
Features
Product colour Black
Housing material Metal
Maximum resolution 4096 x 2160 pixels
HD type 4K Ultra HD
Maximum refresh rate 60 Hz
Bandwidth 600 MHz
HDCP Yes
Number of displays supported 8
LED indicators Yes
Power
DC-in requirements DC 5V@2A Power adapter
Weight & dimensions
Width 140 mm
Depth 50 mm
Height 220 mm
Weight 387 g
Packaging data
Package width 140 mm
Package depth 50 mm
Package height 220 mm
Package weight 756 g
Packaging content
Cables included DC
AC adapter included Yes
Operational conditions
Operating temperature (T-T) 0 - 70 °C
Storage temperature (T-T) -20 - 60 °C
Operating relative humidity (H-H) 20 - 90%
Storage relative humidity (H-H) 5 - 90%
