Microconnect FIB121001 InfiniBand/fibre optic cable 1 m ST SC Yellow

Microconnect FIB121001 InfiniBand/fibre optic cable 1 m ST SC Yellow

£12.96 GBP
£12.96 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

FIB121001

Low stock: 1 left

  • Designed for Data Centers, Industry and Computer Centers
  • LSZH (Low Smoke Zero Halogen) and flame retardant
  • RoHS compliant
Optical Fibre Cable, ST-SC, Singlemode, Duplex, OS2 (Yellow), 1m

Single mode fiber optic cable is suitable for enterprise network, Telecom rooms, server farms, cloud storage networks and any place where fiber jumper cables are needed. This cable is ideal for connecting 1G/10G/40G/100G Ethernet connections. It can transport data for up to 10km at 1310nm, or up to 40km at 1550nm. The single mode patch cords are manufactured using LSZH cables which conform to IEC, EIA TIA or Telcordia standards.

Features
Jacket material Low smoke zero halogen (LSZH)
Insertion loss 0.3 dB
Fiber mode structure Single-mode
Cladding diameter 125 µm
Core diameter 9 µm
Product colour Yellow
Connector 2 SC
Connector 1 ST
Fibre optic type OS2
Cable length 1 m
Technical details
Compliance certificates RoHS
Doesn't contain Halogen
Operational conditions
Storage temperature (T-T) -40 - 85 °C
Operating temperature (T-T) -40 - 85 °C
Weight & dimensions
Weight 50 g
Cable diameter 2 mm
Packaging data
Package weight 100 g
Other features
Core / cladding diameter 9/125 µm
