Microconnect
Microconnect BNC-HDSDI-100R coaxial cable 100 m No
Microconnect BNC-HDSDI-100R coaxial cable 100 m No
SKU:BNC-HDSDI-100R
46 in stock
Couldn't load pickup availability
Delivery & lead times
Delivery & lead times
Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.
Buying 5 or more? Volume pricing
Buying 5 or more? Volume pricing
We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.
Returns & warranty
Returns & warranty
See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.
- Designed in Denmark
- Flexible and durable: Best suited to mobile HD application
- Designed for withstanding repeated bending
- Stranded center conductor
- High-density double-braided shield.
MicroConnect 12G SDI cable supports signals from 12G-SDI, 6G-SDI, HD-SDI and 3G-SDI. The cable is designed for use with your professional equipment that requires an SDI connection. Support 4K60Hz for resolutions up to 4096x2160 & Full HD 1080p.
75ohm. 12G at 75m Max.
Charactistic Impedans: 75+-3Ω
Attenuation Frequency ( MHZ) - Nom. Attenuation ( 20C)
5 - 1.74dB/100m
50 - 4.2dB/100m
200 - 7.8dB/100m
550 - 12.85dB/100m
800 - 16.15dB/100m
1000 - 18.05dB/100m
| Features | |
|---|---|
| Cable length | 100 m |
| Connector 1 | No |
| Connector 2 | No |
| AWG wire size | 16 |
| Jacket outer diameter | 7.3 mm |
| Jacket material | Polyvinyl chloride (PVC) |
| Cable jacket colour | Black |
| Conductor material | Copper |
| Packaging data | |
|---|---|
| Weight | 3.3 kg |
| Package weight | 3.3 kg |
