Logitech LoRaWAN Gateway for Spot gateway/controller 10, 100 Mbit/s

Logitech LoRaWAN Gateway for Spot gateway/controller 10, 100 Mbit/s

Regular price £830.16 GBP
Regular price Sale price £830.16 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

SKU:950-000124

Low stock: 1 left

  • 10,100 Mbit/s Wi-Fi
  • Built-in processor 256 MB 8000 MB
  • Antenna type: External 3 dBi
  • Desktop/Wall mounting IP30
  • White
LoRaWAN Gateway for Logitech Spot

Connect hundreds of Logitech Spot sensors throughout an office, especially in areas without a Logitech CollabOS device like Tap Scheduler or Rally Bar.

ONE GATEWAY, EXTENDED COVERAGE
The Kerlink gateway is able to connect hundreds of sensors using a long-range, wide area network (LoRaWAN). No WiFi, no cabling needed between connections.

SIMPLE TO INSTALL

FIND THE BEST AREA
To maximize coverage, find a central place on the floor or building where the gateway would have the best, unblocked reception.

PROVISION VIA SYNC PORTAL
Remotely provision and configure your gateway via Sync Portal.

CONNECT SENSORS
Activate Spot sensors to ensure complete LoRaWAN connectivity.

POWERED BY LORAWAN
The Kerlink gateway connects to Spot sensors via the secure LoRaWAN protocol, ensuring end-to-end encryption, and is separate from your WiFi network. This enables it to be placed outside your corporate network and securely transmit all sensor data to the Sync platform for monitoring and management.

SIMPLE TO MANAGE
Monitor and manage the gateway and Spot sensors via Sync, the Logitech platform for managing all your collaboration devices and spaces.

Design
Product colour White
Mounting type Desktop/Wall mounting
International Protection (IP) code IP30
Features
Antenna type External
Antenna gain level (max) 3 dBi
Performance
Processor family ARM Cortex
Processor manufacturer ARM
Built-in processor Yes
Internal memory 256 MB
Flash memory 8000 MB
Network
Ethernet LAN data rates 10,100 Mbit/s
Wi-Fi Yes
Frequency band 2.4 GHz
Ports & interfaces
USB 2.0 ports quantity 1
DC-in jack Yes
Ethernet LAN (RJ-45) ports 1
Management features
Reset button Yes
Power
Input voltage 230 V
Output voltage 12 V
Weight & dimensions
Height 160 mm
Depth 35 mm
Width 90 mm
Weight 162 g
Packaging content
Manual Yes
AC adapter included Yes
Operational conditions
Operating temperature (T-T) -20 - 55 °C
Operating relative humidity (H-H) 5 - 95%
