Lindy 45604 networking cable Black 3 m Cat6 S/FTP (S-STP)

Lindy 45604 networking cable Black 3 m Cat6 S/FTP (S-STP)

Regular price £10.21 GBP
Regular price Sale price £10.21 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

SKU:45604

Low stock: 1 left

  • Twisted Pair Patch Cable with RJ45 connectors and Test Report (100% Test)
  • Cat.6 S/FTP PIMF, LSZH
  • Integrated snagless connector for latch protection
  • Gold plated pins for better conductivity and elimination of signal loss
3m Cat.6 S/FTP LSZH Network Cable, Black (Fluke Tested)

Cat.6 S/FTP network cable with support for bandwidth up to 250MHz and features a snagless design with gold plated contacts for ethernet standards up to 1GBase-T.
Cat.6 cable for operating frequencies up to 250MHz in shielded version with braid as overall shield and foil shield for the individual wire pairs (S/FTP).
Cat.6 cables are widespread throughout the professional sector. They are ideal for Gigabit Ethernet or AV extension applications. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag. The 100% Component test slip included in each polybag ensures flawless compatibility between devices, each component of the cable is individually tested helping to eliminate problems such as insertion loss, return loss and crosstalk.
The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.
The halogen-free sheath material of the LSZH cable makes the product suitable for use in public spaces with its low smoke emission and elimination of toxic halogen emissions.
Available lengths: 0.3m, 0.5m, 1m, 2m, 3m, 5m, 7.5m, 10m, 15m, 20m, 30m, 40m, 50m, 60m, 70m, 80m, 90m, 100m.
Available colours: Black, Blue, Gray, Red.

Features
Certification RoHS, REACH, UL
Bend radius (min) 1.86 cm
Frequency 250 MHz
AWG wire size 26
Conductor material Copper
Jacket material Low smoke zero halogen (LSZH)
Connector shield material Aluminium/Polyester
Connector shielding Yes
Connector contacts plating Nickel/Gold
Connector 1 gender Male
Connector 2 gender Male
Connector 2 RJ-45
Connector 1 RJ-45
Product colour Black
Cable shielding S/FTP (S-STP)
Cable standard Cat6
Cable length 3 m
Operational conditions
Storage temperature (T-T) -25 - 60 °C
Operating temperature (T-T) -25 - 60 °C
Weight & dimensions
Connector 1 dimensions (WxDxH) 11.6 x 21.5 x 8.3 mm
Connector 2 dimensions (WxDxH) 11.6 x 21.5 x 8.3 mm
Outer diameter 6.2 mm
Packaging data
Package type Polybag
Logistics data
Harmonized System (HS) code 84733080
