Lindy 4 Port HDMI 18G Switch with Audio

Lindy 4 Port HDMI 18G Switch with Audio

Regular price £97.81 GBP
Regular price Sale price £97.81 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

SKU:38249

26 in stock

  • Switch between 4 HDMI 2.0 source devices connected to a single HDMI 2.0 display
  • Supports resolutions up to 4K 60Hz, with additional support for HDR
  • Extract digital and analogue audio from a HDMI source device
  • Seamless control via IR remote, push button, auto switching and RS232
  • 2 year warranty
4 Port HDMI 18G Switch with Audio

The Lindy 4 Port HDMI 18G Switch with Audio is a professional solution for providing simple yet reliable switching control over 4 HDMI source devices connected to a single HDMI display, while also expanding a displays HDMI port connections. Supporting HDMI 2.0 18G signals, this switch allows for the transmission of detailed 4K Ultra HD resolutions, while additional support for High-Dynamic Range ensures video content can be seen with enhanced brightness, greater contrasts and a much wider colour gamut, perfect for a premium home cinema experience, eye-catching digital signage in retail settings or engaging presentations. HDCP 2.2 support ensures there are no issues with a variety of 4K content when connected to source devices including set top boxes, Blu-Ray players and 4K HDR media players.

As well as HDMI audio pass-through, the switches 3.5mm audio port allows for a separate connection of both analogue speaker systems, and optical audio devices such as soundbars and amplifiers via the included adapter, great for ensuring a multi-channel audio experience to provide a heightened sense of realism for the viewer.

This 4 Port HDMI switch also provides a huge range of seamless control options for the user, to ensure efficient, hassle free usage for both new, and experienced users. The switch itself can be controlled manually via push button switching, while it can also identify the active HDMI source device and automatically switch to this option.

The included remote control allows the user to have convenient control over multiple videos and audio formats from a distance, great for trade show demonstrations or training presentations, while the RS-232 connection can be used for professional PC control of the switch, or integrating it into other automated PC control systems.

Ports & interfaces
DC-in jack Yes
RS-232 ports 1
HDMI in 5
HDMI version 2.0
HDMI ports quantity 5
Video port type HDMI
Features
HDCP Yes
Bandwidth 18 Gbit/s
LED indicators Yes
Maximum resolution 3840 x 2160 pixels
Audio output channels 5.1 channels
HDCP version 2.2
Extended display identification data (EDID) Yes
Consumer Electronics Control (CEC) support Yes
Product colour Black
Material Metal
Certificates
Certification CE. FCC, REACH
Weight & dimensions
Weight 563 g
Height 11.6 mm
Depth 85 mm
Width 180 mm
Packaging data
Package weight 682 g
Package height 183 mm
Package depth 55 mm
Package width 245 mm
Packaging content
Remote control included Yes
AC adapter included Yes
Cables included IR, RS-232
Quantity per pack 1 pc(s)
Operational conditions
Operating relative humidity (H-H) 20 - 90%
Storage temperature (T-T) -20 - 60 °C
Operating temperature (T-T) 0 - 40 °C
Logistics data
Harmonized System (HS) code 85176990
