Lindy 4 Port HDMI 18G Splitter
Lindy 4 Port HDMI 18G Splitter
Couldn't load pickup availability
SKU:38236
Low stock: 2 left
- Split a single HDMI 2.0 source across 4 HDMI displays
- Supports resolutions up to 4K@60Hz 4:4:4, with additional support for HDR
- HDCP 2.2 support for enhanced compatibility
- EDID Management for hassle free installation
- 2 Year Warranty
The Lindy 4 Port HDMI 2.0 18G Splitter is a compact, high quality solution for distributing HDMI 2.0 18G signals across multiple displays from one source device. With support for resolutions up to 4K 60Hz 4:4:4 8bit, this splitter is great for creating eye-catching digital signage in retail scenarios, showing high quality video in different rooms in medical facilities or ensuring audiences do not miss any of the action in dual display sports bars. Additional support for High-Dynamic Range ensures video content can be seen with enhanced brightness, superior contrasts and a much wider colour gamut, for more lifelike colour.
HDCP 2.2 support ensures there are no issues with a variety of 4K content when connected to source devices including set top boxes, Blu-Ray players and 4K HDR media players, while a smart EDID management switch on the unit provides maximum compatibility with the display. The splitters durable, compact design also ensures the unit can be installed discreetly, ensuring there is no distraction from the content on screen.
| Ports & interfaces | |
|---|---|
| Video ports quantity | 5 |
| Video port type | HDMI |
| Video out | 4x HDMI |
| HDMI version | 2.0 |
| DC-in jack | Yes |
| Features | |
|---|---|
| Product colour | Black |
| Housing material | Metal |
| Maximum resolution | 3840 x 2160 pixels |
| HD type | 4K Ultra HD |
| Maximum refresh rate | 60 Hz |
| HDCP | Yes |
| LED indicators | Yes |
| Certification | CE, FCC, REACH, California Proposition 65 |
| Power | |
|---|---|
| AC input voltage | 5 V |
| Input current | 1 A |
| Weight & dimensions | |
|---|---|
| Width | 163 mm |
| Depth | 63 mm |
| Height | 16 mm |
| Weight | 373 g |
| Packaging data | |
|---|---|
| Package width | 248 mm |
| Package depth | 55 mm |
| Package height | 183 mm |
| Package weight | 526 g |
| Package type | Box |
| Packaging content | |
|---|---|
| Manual | Yes |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Technical details | |
|---|---|
| Compliance certificates | RoHS |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85176990 |
