Lindy 0.5m USB 2.0 Type C to B Cable, Anthra Line
Lindy 0.5m USB 2.0 Type C to B Cable, Anthra Line
Couldn't load pickup availability
SKU:36940
13 in stock
- Professional choice USB 2.0 Type C to B cable for commercial and high performance AV and IT installations
- Supports data transfer speeds up to 480Mbps
- Robust PVC housing, nickel connectors and gold plated contacts
- Double shielded cable, corrosion resistant tinned copper conductors
- 10 year warranty
The Anthra Line USB 2.0 Type C to B cables from Lindy's Cable Lines concept are the professional choice for high performance connections in commercial AV and IT installations.
They are premium connections that feature double shielded construction with tinned copper conductors for performance and corrosion resistance. High quality gold plated contacts and nickel plated connectors maintain optimal signal integrity and maximum reliability.
Data transfer speeds up to 480Mbps are supported for the quick and effortless transfer of large data volumes.
USB Type C features a reversible connector, so no matter which orientation the cable is inserted, a connection will always be found. This connector allows a fully bi-directional cable with automatic host and device negotiation.
Anthra Line USB 2.0 Type C to B cables are available in the following length: 0.5m, 1m, 2m and 3m.
| Features | |
|---|---|
| Certification | RoHS, REACH, California Proposition, UL |
| Nominal attenuation | 1 - 400MHz < 5.8dB |
| Cable type | Round cable |
| Product colour | Black |
| Maximum data transfer rate | 0.48 Gbit/s |
| Conductor material | Tinned copper |
| Connector shielding | Yes |
| Connector shield material | Aluminium |
| Cable jacket material | Nylon/Polyvinyl Chloride (PVC) |
| Connector contacts plating | Nickel |
| AWG wire size | 26/28 |
| Connector 2 form factor | Straight |
| Connector 1 form factor | Straight |
| Connector 2 gender | Male |
| Connector 1 gender | Male |
| Connector 2 | USB B |
| Connector 1 | USB C |
| Cable length | 0.5 m |
| USB version | USB 2.0 |
| Weight & dimensions | |
|---|---|
| Connector 2 dimensions (WxDxH) | 11.8 x 47 x 10.2 mm |
| Connector 1 dimensions (WxDxH) | 10.9 x 28.3 x 7.2 mm |
| Cable diameter | 4.4 mm |
| Bend radius (min) | 2.5 cm |
| Packaging data | |
|---|---|
| Package type | Polybag |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | 0 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84733080 |
