Lenovo ThinkCentre neo 30s Gen 5 Intel® Core™ i5 i5-13420H 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro SFF PC Black

Intel Core i5-13420H, 8C (4P + 4E)/12T, P-core 2.1/4.6GHz, E-core 1.5/3.4GHz, 12MB, 1x 16GB SO-DIMM DDR5-5200, 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal, Intel UHD Graphics, Intel Wi-Fi 6 AX203 802.11ax 2x2 + BT5.2, Windows 11 Pro

Processor
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	13th gen Intel® Core™ i5
Processor model	i5-13420H
Processor cores	8
Processor threads	12
Processor boost frequency	4.6 GHz
Performance cores	4
Efficient cores	4
Performance-core Max Turbo Frequency	4.6 GHz
Efficient-core Max Turbo Frequency	3.4 GHz
Processor cache	12 MB
Processor cache type	Smart Cache
Maximum turbo power	95 W
Processor base power	45 W

Neural processor unit (NPU)
Neural processor unit (NPU)	No

Memory
Internal memory	16 GB
Maximum internal memory	64 GB
Internal memory type	DDR5-SDRAM
Memory layout (slots x size)	1 x 16 GB
Memory slots	2x SO-DIMM
Memory clock speed	5200 MHz

Storage
Total storage capacity	512 GB
Optical drive type	No
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	PCI Express 4.0
NVMe	Yes
SSD form factor	M.2
Card reader integrated	No

Graphics
Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card family	Intel® UHD Graphics
On-board graphics card model	Intel® UHD Graphics

Network
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000 Mbit/s
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller manufacturer	Intel
Wi-Fi standards	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX203
Antenna type	2x2
Bluetooth	Yes
Bluetooth version	5.2

Ports & interfaces
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
VGA (D-Sub) ports quantity	1
HDMI ports quantity	1
HDMI version	2.1
Ethernet LAN (RJ-45) ports	1
Microphone in	Yes
Line-out	Yes
Combo headphone/mic port	Yes

Design
Chassis type	SFF
Colour name	Chassis: Black, Bezel: Grey
Volume	8.2 L
Cable lock slot	Yes
Cable lock slot type	Kensington
Product colour	Black

Performance
Product type	PC
Motherboard chipset	Intel SoC
Audio chip	Realtek ALC623-CG
Audio system	High Definition Audio
Number of speakers	1
Trusted Platform Module (TPM)	Yes

Software
Operating system installed	Windows 11 Pro
Operating system language	English

Power
Power supply	180 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50/60 Hz

Certificates
Certification	TCO

Weight & dimensions
Width	92.5 mm
Depth	291.7 mm
Height	339.5 mm
Weight	4.63 kg

Packaging content
Display included	No
Mouse connectivity	Wired
Mouse included	Yes
Keyboard connectivity	Wired
Keyboard included	Yes

general_information_attribute_container_name
Product series	neo
attribute_product_family_name	ThinkCentre

Technical details
Box contents	Slim ODD Bracket Kit
