• Kioxia CD8-R 15.4TB 2.5-inch PCI Express 4.0 NVMe BiCS FLASH TLC solid state drive
1 1

Kioxia

Kioxia CD8-R 15.4 TB 2.5" PCI Express 4.0 NVMe BiCS FLASH TLC

Kioxia CD8-R 15.4 TB 2.5" PCI Express 4.0 NVMe BiCS FLASH TLC

KCD8XRUG15T3

£8,126.90 GBP£6,772.42 GBP
£0.00 GBP £8,126.90 GBP£6,772.42 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

60 in stock

Delivery & lead times

Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.

Buying 5 or more? Volume pricing

We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.

Returns & warranty

See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.

  • PCIe® 4.0, NVMe™ 1.4 specification compliant Help Modal Window
  • Open Compute Project Datacenter NVMe™ SSD specification v2.0 support (not all requirements)
  • Form factor: 2.5-inch, 15mm height Help Modal Window
  • Proprietary KIOXIA architecture: controller, firmware and 112-layer BiCS FLASH™ 3D TLC Help Modal Window
  • Single-port design, optimized for data center class workloads
  • Consistent performance and reliability for demanding 24x7 environments
  • Designed for high-density storage deployments
  • Power loss protection (PLP) and end-to-end data correction
  • Security options: SIE, SED
2,5", 15360 GB, PCIe 4.0, NVMe 1.4, BiCS FLASH TLC, 6600 MB/s read, 6000 MB/s write

Data Center NVMe Read-intensive SSD
The CD8-R Series is a read-intensive data center NVMe™ SSD that is optimized to support a broad range of scale-out and cloud applications, including big data/IoT, online transaction processing, and virtualization. Built with a PCIe® 4.0 (16 GT/s x4) interface, CD8-R Series SSDs deliver consistent performance up to 1,250K IOPS (random read) and 200K IOPS (random write).

Featuring KIOXIA 112-layer BiCS FLASH™ 3D TLC flash memory, CD8-R 2.5-inch form factor SSDs deliver 1 DWPD (Drive Writes Per Day) of endurance and storage capacities up to 15.36 TB in a 2.5-inch form factor, making them well-suited for hyperscale data center applications.

Features
SSD form factor 2.5"
SSD capacity 15.4 TB
Interface PCI Express 4.0
NVMe Yes
NVMe version 1.4
Memory type BiCS FLASH TLC
Component for Server/workstation
Read speed 6600 MB/s
Write speed 6000 MB/s
Random read (4KB) 1050000 IOPS
Random write (4KB) 195000 IOPS
PCI Express interface data lanes x4
Mean time between failures (MTBF) 2500000 h
Power
Operating voltage 12 V
Power consumption (max) 20 W
Operational conditions
Operating temperature (T-T) 0 - 74 °C
Storage temperature (T-T) -40 - 85 °C
Minimum operating temperature 0 °C
Maximum operating temperature 74 °C
Operating relative humidity (H-H) 5 - 95%
Operating vibration 2.17 G
Operating shock 1000 G
Technical details
Warranty period 5 year(s)
Weight & dimensions
Width 69.8 mm
Depth 100.5 mm
Height 15 mm
Weight 130 g
