Intel
Intel Wi-Fi 7 BE202 Internal WLAN / Bluetooth 2400 Mbit/s
Intel Wi-Fi 7 BE202 Internal WLAN / Bluetooth 2400 Mbit/s
Regular price
£14.51 GBP
Regular price
Sale price
£14.51 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
SKU:BE202.NGWG.NV
Low stock: 4 left
- Wireless
- M.2 WLAN / Bluetooth
- 2400 Mbit/s
- Wi-Fi Tri-band (2.4 GHz / 5 GHz / 6 GHz) Bluetooth 5.4
- Internal Component for: PC/Laptop
Intel WiFi 7 BE202
Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.
| Ports & interfaces | |
|---|---|
| Interface | WLAN / Bluetooth |
| Host interface | M.2 |
| Connectivity technology | Wireless |
| Network | |
|---|---|
| MU-MIMO | Yes |
| Bluetooth version | 5.4 |
| Bluetooth | Yes |
| Security algorithms | AES-CCMP, AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Wi-Fi | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w |
| Maximum data transfer rate | 2400 Mbit/s |
| Design | |
|---|---|
| Antenna type | 2x2 |
| Component for | PC/Laptop |
| Internal | Yes |
| System requirements | |
|---|---|
| Linux operating systems supported | Yes |
| Windows operating systems supported | Windows 10, Windows 11 |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 80 °C |
| Sustainability | |
|---|---|
| Sustainability compliance | Yes |
| Weight & dimensions | |
|---|---|
| Weight | 3.07 g |
| Height | 2.4 mm |
| Depth | 30 mm |
| Width | 22 mm |
| Technical details | |
|---|---|
| Compliance certificates | CB, UL |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8517620090 |
| Other features | |
|---|---|
| Launch date | Q3'23 |
| Status | Launched |
| Ethernet adapter ARK ID | 234444 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
