Intel
Intel Wi-Fi 7 BE201 Internal WLAN / Bluetooth 5000 Mbit/s
Intel Wi-Fi 7 BE201 Internal WLAN / Bluetooth 5000 Mbit/s
SKU:BE201.NGWG
66 in stock
Couldn't load pickup availability
Delivery & lead times
Delivery & lead times
Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.
Buying 5 or more? Volume pricing
Buying 5 or more? Volume pricing
We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.
Returns & warranty
Returns & warranty
See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.
- Wireless
- M.2 WLAN / Bluetooth
- 5000 Mbit/s
- Wi-Fi Tri-band (2.4 GHz / 5 GHz / 5 GHz) Bluetooth 5.4
- Internal Component for: PC/Laptop
Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.
| Ports & interfaces | |
|---|---|
| Interface | WLAN / Bluetooth |
| Host interface | M.2 |
| Connectivity technology | Wireless |
| Network | |
|---|---|
| Bluetooth version | 5.4 |
| Bluetooth | Yes |
| Security algorithms | 128-bit AES, 256-bit AES, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, WPA2, WPA3 |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 5 GHz) |
| Wi-Fi | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11j, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w |
| Maximum data transfer rate | 5000 Mbit/s |
| Design | |
|---|---|
| Form factor | M.2 2230 |
| Antenna type | 2x2 |
| Component for | PC/Laptop |
| Internal | Yes |
| System requirements | |
|---|---|
| Linux operating systems supported | Yes |
| Windows operating systems supported | Windows 10, Windows 11 |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 50 - 90% |
| Operating temperature (T-T) | 0 - 50 °C |
| Weight & dimensions | |
|---|---|
| Weight | 3.06 g |
| Height | 2.42 mm |
| Depth | 30 mm |
| Width | 22 mm |
| Technical details | |
|---|---|
| Compliance certificates | CB, UL |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8517620090 |
| Other features | |
|---|---|
| Status | Launched |
| Ethernet adapter ARK ID | 230079 |
| Export Control Classification Number (ECCN) | 5A991B |
| Supported Under vPro | Yes |
