Intel Wi-Fi 7 BE200 Internal WLAN / Bluetooth 5800 Mbit/s
Intel Wi-Fi 7 BE200 Internal WLAN / Bluetooth 5800 Mbit/s
SKU:BE200.NGWG
13 in stock
Couldn't load pickup availability
Delivery & lead times
Delivery & lead times
Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.
Buying 5 or more? Volume pricing
Buying 5 or more? Volume pricing
We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.
Returns & warranty
Returns & warranty
See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.
- Wireless
- M.2 WLAN / Bluetooth
- 5800 Mbit/s
- Wi-Fi Tri-band (2.4 GHz / 5 GHz / 6 GHz) Bluetooth 5.4
- Internal Component for: PC/Laptop
Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.
| Ports & interfaces | |
|---|---|
| Connectivity technology | Wireless |
| Host interface | M.2 |
| Interface | WLAN / Bluetooth |
| Network | |
|---|---|
| Maximum data transfer rate | 5800 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w |
| Wi-Fi | Yes |
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| Security algorithms | AES-CCMP, AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3 |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| MU-MIMO | Yes |
| Design | |
|---|---|
| Internal | Yes |
| Component for | PC/Laptop |
| Antenna type | 2x2 |
| System requirements | |
|---|---|
| Windows operating systems supported | Windows 10, Windows 11 |
| Linux operating systems supported | Yes |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 80 °C |
| Sustainability | |
|---|---|
| Sustainability compliance | Yes |
| Weight & dimensions | |
|---|---|
| Width | 22 mm |
| Depth | 30 mm |
| Height | 2.4 mm |
| Weight | 3.07 g |
| Technical details | |
|---|---|
| Compliance certificates | CB, UL |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8517620090 |
| Other features | |
|---|---|
| Maximum operating temperature | 70 °C |
| Compliance | FIPS |
| Supported Under vPro | Yes |
| Embedded options available | No |
| Intel Trusted Execution Technology | No |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Export Control Classification Number (ECCN) | 5A992C |
| Ethernet adapter ARK ID | 230078 |
| Status | Launched |
| Product brief URL | https://www.intel.com/content/www/us/en/secure/content-details/916611/intel-wi-fi-7-be200-5gig-module-commercial-temperature-embedded-module-product-brief.html?DocID=916611 |
| Launch date | Q3'23 |
